Discontinued
22MP48D-P
22'' Full HD IPS LED Monitor (22'' Diagonal)
  • IPS Display
  • Reader Mode / Flicker Safe
  • On Screen Control
  • Screen Split / PIP
  • Colour Weakness Mode
22" Full HD IPS LED Monitor (22" Diagonal)

General

  • Size (Inch / cm)
    21.5“ / 54.6cm
    Panel Type
    IPS
  • Colour Gamut (CIE1976)
    72%
    Colour Depth (Num of Colours)
    16.7M colours
  • Pixel Pitch (mm)
    0.24795 x 0.24795
    Aspect Ratio
    16:9
  • Resolution
    1920 x 1080
    Brightness (Typ.)
    250cd/m2
  • Contrast Ratio (Original)
    1000:1
    (DFC)
    Mega
  • (GTG)
    14ms
    Viewing Angle (CR≥10)
    178/178
  • Surface Treatment
    Anti-Glare,3H

JACK INPUT/OUTPUT

  • D-Sub
    Yes
    DVI-D
    Yes
  • Jack Location (Signal Input)
    Back (horizontal)

POWER

  • Type
    Adapter
    Input
    100-240Vac, 50/60Hz
  • Output
    19V/1.3A
    Normal On (EPA)
    20W
  • Normal On (typ.)
    23W
    Sleep Mode (Max)
    0.3W
  • DC Off (Max)
    0.3W

FREQUENCY

  • D-sub (H-Frequency)
    30~83kHz
    D-sub (V-Frequency)
    56~75Hz
  • DVI-D (H-Frequency)
    30~83kHz
    DVI-D (V-Frequency)
    56~75Hz

RESOLUTION

  • PC (D-sub)
    1920 x 1080
    Digital (DVI-D / HDMI)
    1920 x 1080

Control Key

  • Key Number (Power Key Included)
    6
    Key Type
    Tact Type
  • LED Colour (On mode)
    White
    LED Colour (Power save mode)
    White Blinking
  • [ Key Location ]
    Bottom

OSD

  • Country
    English, German, French, Spanish, Italian, Swedish, Finnish, Portuguese, Polish, Russian, Greek, Chinese, Japanese, Korean, Ukrainian, Portuguese(brazil), Hindi
    Number of Language
    17

Special Features

  • Picture Mode
    Yes
    Reader Mode
    Yes
  • Original Ratio
    Yes
    DDC/CI
    Yes
  • HDCP
    Yes
    Intelligent Auto (Auto Adjustment)
    Yes
  • Key Lock
    Yes
    Plug & Play
    Yes
  • Colour weakness
    Yes
    Flicker Safe
    Yes
  • Six Axis Control
    Yes
    Smart Energy saving
    Yes
  • 4 screen split
    Yes
    On Screen Control (OSC)
    Yes

Colour

  • Front
    Black high glossy
    B/Cover
    Black hairline + texture
  • Stand
    Black high glossy
    Base
    Black high glossy
  • Others
    Black Texture

STAND

  • Base Detchable
    Yes
    Tilt (Angle)
    Yes / -5º (front) ~ 20º(rear)

Dimensions - WxDxH(mm)

  • Set (with Stand)
    508.4 x 187.4 x 387.6
    Set (without Stand)
    508.4 x 57.3 x 313.1
  • Box
    577 x 381 x 118

WEIGHT(KG)

  • Set (with Stand)
    2.7
    Set (without Stand)
    2.5
  • Box
    4

Wall Mount

  • Wall Mount size (mm)
    75 x 75

Stuffing

  • Pallet (20ft/40ft/40ft HC)
    900/1980/2200

Wrap

  • Packing Material
    EPS
    Stacking Type
    Face Down
  • Stand Packing Type
    None
    Box Printing Type
    Flexo
  • Handle
    Hand Hole

Standard

  • UL (cUL)
    Yes
    TUV-Type
    Yes
  • FCC-B, CE
    Yes
    EPA 6.0
    Yes
  • EPEAT
    Yes (Gold)
    Windows
    Yes (Win10)

Accessory

  • Power Cord
    Option
    D-Sub
    Option
  • DVI-D
    Option

COMPLIANCE INFORMATION
