55SH7DD-B
SH7DD Series
  • Brightness(Typ.) : 700 cd/m²
  • Bezel : T/L/R 11.9 mm, B 18.0 mm
  • Depth : 54 mm(38.6mm:Thinnest Part)
  • Interface : HDMI(2), DVI, RGB, RJ45, IR, RS232C, USB
  • Built-in Speaker
  • USB Content Scheduling, PM Mode, Local Time Auto Setting, No Signal Image
SH7DD Series
MSRP £
*Based on 49" model
*Supported Content Type: Video (MPEG1/2/4, H.264),Audio (MP3, AC3, MPEG, AAC, HEAAC, LPCM), Image (JPEG, PNG, BMP)
*SNMP: Simple Network Management Protocol
* NTP: Network Time Protocol

Panel

  • Screen Size
    55"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness(Typ.,cd/m²)
    700

Connectivity

  • Input
    HDMI (2), DVI, RGB, Audio, USB 2.0
    Output
    Audio
  • External Control
    RS232C In/Out, RJ45 In, IR Receiver In

Physical Specification

  • Bezel Width
    11.9 mm (T/R/L), 18 mm (B)
    Monitor Dimension (W x H x D)
    1,238 x 714.9 x 54 mm
  • Weight (Head)
    17.5 kg
    VESA™ Standard Mount Interface
    300 x 300

Environment Conditions

  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %

Power

  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power

Power Consumption

  • Typ.
    95 W
    Smart Energy Saving
    75 W

Standard(Certification)

  • Safety
    UL / cUL / CB / TUV / KC
    EMC
    FCC Class "A" / CE / KCC
  • ErP / Energy Star
    N/A / Yes (Energy Star 8.0)

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible
    No
    External Media player Attatchable
    Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign Premium
    Control and Monitoring Software
    SuperSign C

Accessory

  • Basic
    Remote Controller (include battery 2ea), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, IR Receiver
    Optional
    Stand (ST-492T), Media player, Wall bracket (LSW350B), VESA Adapter (AM-B330S), Wi-Fi Dongle (AN-WF500), Touch Overlay (KT-T550)
