Key Feature

  • Welcome Screen/Video
  • USB Cloning
  • NEW WOL (Wake on LAN) & SNMP
  • USB Auto Playback +
  • Time scheduler

All Spec

VIDEO

  • XD Engine

    Yes

  • Picture Mode

    8 modes (Vivid, Standard, Eco, Cinema, Sport, Game, Expert1, Expert2)

  • Aspect Ratio

    6 modes (16:9, Original, 4:3, Vertical Zoom, All-Direction Zoom, Just Scan)

POWER

  • Power Supply

    100-240V, 50/60HZ

  • Energy saving (Max)

    22.3W

  • Typ/Max

    74.2W/98.1W

  • Stand-by

    0.3W

AUDIO

  • Audio Output / Speaker System

    10W + 10W / 2.0 ch

  • Sound mode

    • 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)

DISPLAY

  • Brightness

    400 cd/m2

  • Type

    Direct LED

  • Resolution

    1,920 x 1,080 (FHD)

BROADCASTING SYSTEM

  • Analog

    PAL / SECAM

  • Digital

    DVB-T2/C/S2

FEATURES

  • Installation

    USB Cloning

  • Management

    WOL (Wake on LAN), SNMP, Self Diagnostics, IR Out, Multi IR Code, HTNG/HDMI-CEC

  • Hospitality

    Hotel Mode, Lock Mode, Welcome Screen/Video, Insert Image, One Channel Map, External Speaker Out, RJP Compatibility, USB Auto Playback+, Crestron Connected® Certified, Time Scheduler

INTERFACE

  • Side

    Headphone Out, HDMI In, USB 2.0, CI Slot

  • Rear

    RF In (2), AV In, Component In (Audio, RCA5), Digital Optical Audio Out, HDMI/HDCP Input, RGB In, PC Audio Input, RS-232C, RJ45 (SNMP), External Speaker Out

CABINET(UNIT : MM)

  • Vesa

    300 x 300

  • W x H x D/ Weight (w/o Packing, w/ Stand)

    1,107 x 701 x 235 / 11.42kg

  • W x H x D / weight (w/ Packing, w/ Stand)

    1,193 x 770 x 158 / 13.5kg

CERTIFICATION

  • EMC

    CE

  • ErP Class

    A+

  • Safety

    CB , CU TR
