Key Features
Control Display
LED
Cavity Material
Enamel
Cooktop Color
Stainless Steel
Cooktop Control Type
Knob
Cooktop Finish
Stainless Steel
Door Color
Essence White
Handle Color
Light Bronze
Handle Material
Aluminum
Knob Color
Light Bronze
Knob Lighting
Yes
Knob Material
Aluminum
Outcase Color
Essence White
Oven Control Type
Backlit Glass Touch(LED)
Oven Door Feature
Instaview & WideView Window
Printproof Finish
No
Air Fry Tray (Ea)
1
Conversion Kit (Ea)
1
Gliding Rack (Ea)
1
Griddle Plate (Ea)
1
Heavy Duty Rack (Ea)
1
Offset Rack (Ea)
1
Temp Probe (Ea)
1
Wok Grate (Ea)
1
Bar Code
195174070031
Brand
LG STUDIO
Cooktop Type
Sealed Burner
Fuel Type
Gas
Outcase Color
Essence White
Oven Cooking System
ProBake Convection
Oven Type
Single
Range Type
Slide-In
ADA Compliant
Yes
Control Lock
Yes (Oven)
Cooking Complete Reminder Volume
Yes
Delayed Timed Cook
Yes
Instaview
Yes
Kitchen Timer
Yes
Oven Cleaning Type
EasyClean + Self Clean
Sabbath Mode
Yes
Self-Clean Oven Door Lock
Automatic
Soft Closing System
Yes(Oven Door)
Timed Cook
Yes
Cooktop Type
Sealed Burner
Cooktop Burner Grate Features
Edge-to-edge continuous grates
Cooktop Burner Grate Material
Cast Iron
EasyClean Cooktop
Yes
Element/Burner Type(Dual)
Right Front
Element/Burner Type(Oval)
Center Middle
Element/Burner Type(Single)
Left Front, Left Rear, Right Rear
Fuel Type
Gas
Gas Burner - Center Middle(LNG/LPG) (BTU)
10000 / 10000
Gas Burner - Left Front(LNG/LPG) (BTU)
20000 / 12500
Gas Burner - Left Rear(LNG/LPG) (BTU)
9100 / 7500
Gas Burner - Right Front(LNG/LPG) (BTU)
22000 / 16000
Gas Burner - Right Rear(LNG/LPG) (BTU)
5000 / 4000
Gas Burner Simmer - Center Middle (LNG/LPG)(BTU)
2700 / -
Gas Burner Simmer - Left Front (LNG/LPG)(BTU)
1500 / -
Gas Burner Simmer - Left Rear (LNG/LPG)(BTU)
1270 / -
Gas Burner Simmer - Right Front (LNG/LPG)(BTU)
800 / -
Gas Burner Simmer - Right Rear (LNG/LPG)(BTU)
670 / -
Gas Burner - Total(LNG/LPG) (BTU)
66100 / 50000
Griddle Simmer (LNG/LPG)(BTU)
2700 / -
Number of Cooktop Elements/Burners
5
Safety function(Cooktop)
No
Drawer Dimensions (W x H x D) (inch)
22 5/16 x 4 1/16 x 15 15/16
Oven Interior Dimensions (W x H x D) (inch)
24 14/16 x 22 2/16 x 19 15/16
Overall Depth - including handle (inch)
29 3/8
Packing Dimensions (W x H x D) (inch)
32 11/16 x 43 5/16 x 30 1/2
Product Dimensions (W x H x D) (inch)
29 7/8 x 37 1/4 x 29 3/8
Product Weight (lb.)
162
Shipping Weight (lb.)
224
Size in Width (inch)
30
Drawer Type
Storage
Drawer Time Control
No
Bake Element Type
Hidden
Automatic Safety Shut-Off
Yes
Bake Element(LNG/LPG) (BTU/h)
19000 / 17000
Broil Element Power(LNG/LPG) (BTU/h)
13500 / 12500
Convection Conversion
Yes
Convection Fan
Single Speed
Convection Type
ProBake Convection
Fuel Type
Gas
GoCook Smart Oven Light
Yes
Number of Rack Positions
7
Oven Capacity (cu.ft.)
6.3
Oven Cooking mode
Air Fry, Air Sous-Vide, Bake, Broil, Convection Bake, Convection Roast, Frozen Meal, Keep Warm, Proof, Warm
Oven Light Type
Halogen
Required Power Supply (Volt/Hz)
120V / 60Hz
Amp Rating at 120V (A)
4.2
Watt Rating at 120V (W)
504
SmartDiagnosis
Yes
NFC Tag On
No
Proactive Customer Care
Yes
Smart Recipe (3rd Party Recipe App)
No
ThinQ(Wi-Fi)
Yes
Voice Control (3rd Party Device)
Yes
Works with
Amazon Alexa, Google Assistant, LG ThinQ
NFC
No
Proactive Customer Care
Yes
Remote Control
Yes
Remote Monitoring
Yes
Smart Diagnosis
Yes
ThinQ(Wi-Fi)
Yes
Child-Lock Indicator
No
Fingerprint Resistant
No
Rinse Refill Indicator
Yes
Salt Refill Indicator
No
SignaLight™ Cycle Indicator Lights
3
Status Indicators
3 Indicator Lights
Temperature Display
No
Time Remaining Indicator
LED
Tub Light(Tub Lamp)
Yes
Tub Material
NeveRust™ Stainless Steel
Bar Code
195174070130
Control Panel(Material)
ABS
Display Type
LED
Handle Type
Metal Handle
Panel Type
Top Control
Total Place Settings
15
Number of Wash Cycles (Program)
7
1 Hour
Yes
Auto
Yes
Cancel
Yes
Control Lock
Yes
Delay Start
Yes
Delicate
Yes
Download Cycle
Yes
DryBoost
Yes
Dual Zone
No
Eco
No
Energy Saver
No
Express
No
Extra Dry
Yes
Half Load
No
Heavy
Yes
High Temp.
Yes
Intensive
No
Machine Clean
Machine Clean(Steam)_Download Cycle
Normal
Yes
Number of Options
8
Refresh
Yes
Rinse
No
Steam
Yes
Turbo
No
Packing Dimensions - WxHxD (in)
28 1/32 x 34 7/8 x 29 5/8
Packing Weight (lbs)
110
Product Dimensions - WxHxD (in)
24 3/4 x 33 5/8 x 24 5/8
Product Weight (lbs)
97
CEE Tier Level
1
Energy Star
Yes
Energy Use (kWh/Year)
238
Water Use (Gallons/Cylce)
2.9
Manufacturer
LGEKR
Aqua-Stop
No
Detergent and Rinse-Aid Dispenser
Yes
DirectDrive Motor™
Yes
Drying System
Dynamic Heat Dry
Hidden Water Heater
Yes
Inverter Direct Drive Motor
Yes
LoDecibel Quiet Operation (dBA)
40
Number of Spray Arms
23
QuadWash™
Yes
Safety Float Switch (Leaks)
Yes
SenseClean Wash System
Yes
Soil (Turbidity) Sensor
Yes
TrueSteam™
Yes
Vario Washing System
Yes
Water Softner
No
Cutlery Baskets
Yes
EasyRack™ Plus System
Yes
Gliding Type 3rd
No
Gliding Type_Lower
Yes
Gliding Type_Upper
Yes
Height Adjustable 3rd Rack
Yes(Adjustable)
Maximum Height of Lower Rack (in)
12 1/2
Maximum Height of Upper Rack (in)
12
CAPACITY - Volume Total (cu.ft)
26.5
DIMENSIONS & WEIGHT - Packing Dimension (WxHxD, inch)
38" x 73" x 32"
PERFORMANCE - Energy Consumption (kWh/Year)
632
BASIC SPEC - ENERGY CONSUMPTION GRADE
ENERGY STAR<sup>®</sup> Certified
PERFORMANCE - Compressor Type
Smart Inverter Compressor (BLDC)
FEATURES - InstaView
No
FEATURES - Door-in-Door
No
SMART TECHNOLOGY - ThinQ (Wi-Fi)
Yes
MATERIAL & FINISH - Finish (Door)
Essence White
Brand
LG STUDIO
ENERGY CONSUMPTION GRADE
ENERGY STAR® Certified
Product Type
French Door (3Door)
Standard/Counter Depth
Counter Depth
ThinQ (Wi-Fi)
Yes
Smart Diagnosis
Yes
Volume Total (cu.ft)
26.5
Volume Freezer (cu.ft)
8.7
Volume Refrigerator (cu.ft)
17.8
Internal LED Display
LED Display
Door alarm
Yes
Express Freeze
Yes
Door Cooling+
Yes
Auto Closing Door Hinge
No
Door-in-Door
No
InstaView
No
Sabbath Mode
Yes
Energy Consumption (kWh/Year)
632
Compressor Type
Smart Inverter Compressor (BLDC)
Water Only Dispenser
Internal
Automatic Ice Maker
Yes (In Cabinet, Factory Installed)
Daily Ice Production (lb.)
2.3 / 3.0 (IcePlus)
Dispenser Light
No
Dual lce Maker
No
Ice Maker_Manual
No
Ice Storage Capacity (lb.)
4.0
Water Filter Model Name
LT1000P
Water Filtration System
Internal (1 stage)
Shelf_Folding
No
Door Basket_Moving Basket
No
Door Basket_Transparent
8
Refrigerator Light
Top LED
Shelf_Cantilevered
Yes (Hybrid)
Shelf_Tempered Glass
4 Split(3 Fixed+1Folding)
Vegetable Box
Yes (2)
Wide Pantry
Yes
Convertible Drawer
No
Full-Convert Drawer
No
Door Type
Pull Drawer
Drawer Divider
Yes
Drawer_Freezer
1 Transparent
Durabase Solid Drawer Base
No
Freezer Light
Top LED
Handle Type
Bar (Easy Open)
Contour Door
Flat
Fingerprint & Smudge Resistant Exterior
Yes
Finish (Door)
Essence White
Flat Metal Duct (Metal Fresh)
R Metal
Product Weight (lb.)
256
Depth without door (inch)
24 3/4"
Depth without handle (inch)
29 1/8"
Depth with handle (inch)
31 3/4"
Gross Weight (lb.)
278
Height to Top of Case (inch)
68 7/8"
Height to Top of Hinge or Door Cap Deco (inch)
70 1/4"
Installation Clearance
Back 2"
Packing Dimension (WxHxD, inch)
38" x 73" x 32"
Product Dimension (WxHxD, inch)
35 3/4" x 70 1/4" x 31 3/4"
Total Depth with Door 90 Open (inch)
43 5/8"
Width door open 90 without Handle (inch)
40"
Width door open 90 with Handle (inch)
44 7/8"
Bar Code
195174070116
