- 標配 UV nano 殺菌燈
- 標配雙雷射微塵感知器和二氧化碳偵測感知器
- 標配高效率 PM1.0/PM2.5/PM10 過濾器
- 選購 WiFi 介面進行遠端監控操作
所有規格
基本規格
電源 (Ø, V, Hz)
1Ø 220-240V 50/60Hz
風速
超高 / 高 / 低
電流(A)
0.59 / 0.51 / 0.26
入力(W)
79 / 71 / 30
風量(CMH)
200 / 200 / 100
機外靜壓(Pa)
100 / 70 / 50
溫度交換效率(%) (Heating)(ErP)
82
溫度交換效率(%) (Heating)(JIS)
78 / 78 / 82
溫度交換效率(%) (Cooling)(JIS)
70 / 70/ 81
焓交換效率(%) (Heating)(JIS)
75 / 75 / 81
焓交換效率(%) (Cooling)(JIS)
68 / 68 / 76
噪音(聲壓)
30 / 28 / 22
連接風管
尺寸 (Ø) (mm)
125
數量 (EA)
4
風扇馬達
進氣風扇(RPM)
2,050 / 1,910 / 1,400
排氣風扇(RPM)
1,910 / 1,770 / 1,320
最大轉速(RPM)
2,100
最小轉速(RPM)
1,000
濾網
濾網等級 (ISO 16890)
ePM<sub>1</sub>
寬x高x深(mm)
278 x 276 x 50
特殊功能
UV殺菌燈
Yes
PM(1.0;2.5;10)顯示
PM:1.0;2.5;10搭配有線控制器:PREMTB100 (選配)
二氧化碳濃度(偵測/顯示)
偵測/顯示搭配有線控制器:PREMTB100 (選配)
WIFI控制
選配 (PWFMDD200)
旁通模式
電流(A)
0.60 / 0.52 / 0.29
入力(W)
84 / 73 / 35
風量(CMH)
200 / 200 / 100
機外靜壓(Pa)
100 / 70 / 50
運轉範圍/機身尺寸和重量
室外空氣溫度/相對濕度(℃ / %)
-10 ~ 40 / 20 ~ 80
尺寸 (寬x高x深mm)
640 x 320 x 640
淨重(kg)
23
