B70AWY-9L6

Ducted System - High Static 20kW (Cooling)

(0)
Wi-Fi Smart Control Compatible

Come Home to Comfort

The LG ThinQ® App* lets you access and control your air conditioner with your smartphone* even when you're not at home, so you can come home to comfort. (Optional Wi-Fi dongle module sold separately).

*Wi-Fi Dongle Module required. Sold separately. Feature can be accessed using LG ThinQ® App on Android (v 4.1 or later) iOS (v iOS9 or later) smartphone. Internet connection required.

*LG ThinQ® app available from Google Play Store or Apple App required, for this feature, compatible with Android or iOS smartphones required (Android OS 7.0 or higher, iOS 14.0 or higher).Phone and Home Wi-Fi Data connection and product registration with LG ThinQ® required. Visit lg.com/au/lg-thinq for features, system compatibility and service availability which may vary by model.



    Zone Control<br>1

    Zone Control

    It is possible to control up to 8 zones from the premium controller and indicate a zone name such as Office, Hallway, etc. There are 18 names to choose from.

    *Premium Controller sold separately.

    Premium Controller1

    Touch Colour Screen Controller*

    Premium Controller

    The LG Individual controller provides an intuitive GUI with colour LCD and touchscreen interface. It provides additional visibility on filter cleaning status and energy usage, and the user-friendly button layout allows easy control of features such as Zone Control, Child Lock and Home Leave.

    Premium-Controller_D

    *Sold Separately

    Unoccupied Mode<br>1

    Unoccupied Mode

    When you leave your home unoccupied, instead of turning your system off and letting your home get hot or cold, you can press the dedicated unoccupied button which will set the room temperature to stay between a range of two set temperature points. This allows for a quicker return to a comfortable indoor environment when you return.

    *Home Leave Set Temperature function can only be used in a 2 set control mode.

    Download Ducted Brochure<br>1

    Download Ducted Brochure

    Download a copy of the Ducted brochure for more information.

    Get a quote

    Get a quote

    Looking for the perfect LG Air Conditioner for your home? Contact one of our Specialist Dealers for a FREE, no obligation quote.

    All Spec

    GENERAL

    • Cooling Capacity Max(W)

      22000

    • Cooling Capacity Rated/Min(W)

      20000/8000

    • Cooling Power Consumption Rated/Min(W)

      6470

    • Est. Cooling Area (Sq. Ft.)

      -

    • Est. Heating Area (Sq. Ft.)

      -

    • Heating Capacity Max(W)

      24900

    • Heating Capacity Rated/Min(W)

      22600

    • Heating Consumption Power Rated/Min(W)

      6190

    • Indoor Unit Dimension_WxHxD(mm)

      1,563 x 458 x 791

    • Indoor Unit Weight(kg)

      89

    • Indoor Unit Weight(lb.)

      -

    • Outdoor Unit Dimension_WxHxD(mm)

      1,090 x 1,625 x 380

    • Outdoor Unit Weight(kg)

      144

    • Outdoor Unit Weight(lb.)

      -

    • Product Dimension_WxHxD(mm)

      -

    • Product Type

      -

    • Product Weight(kg)

      -

    • Product Weight(lb.)

      -

    • Rated Input Voltage(V, Hz)

      -

    • Refrigerant Type

      R410A

    • Sound Power(Cooling) SH/H/M/L/SL(dB(A))

      71

    • Sound Power(Heating) SH/H/M/L/SL(dB(A))

      71

    COOLING

    • 4way

      -

    • Airflow direction control (left & right)

      -

    • Airflow direction control (up & down)

      -

    • Comfort Air

      -

    • Fan Speed

      -

    • Power Cooling

      -

    AIR PURIFYING

    • Air Purifying Display

      -

    • Ionizer

      -

    • PM 1.0 Sensor

      -

    DEHUMIDIFICATION

    • Dehumidification

      -

    • Humidity Sensor

      -

    HEATING

    • Power Heating

      -

    ENERGY SAVING

    • Active Energy Control

      -

    • Dry Contact

      -

    • Energy Display

      -

    • Energy Grade

      -

    • Energy Monitoring

      -

    • Energy Saving(Cooling)

      -

    • ICA(I control Ampere)

      -

    CONVENIENCE

    • Auto Restart

      -

    • Fan Mode

      -

    • Filter Alarm

      -

    • Forced Switch Operation

      -

    • Human Body Detecting

      -

    • Low Noise

      -

    • On/Off Reservation(24Hr)

      -

    • Remote Controller

      -

    • Reservation

      -

    • Smart Diagnosis

      -

    • Smart Guide

      -

    • Stabilizer Free opreation

      -

    • Tropical Night Comport Sleep

      -

    • Voice Control (3rd Part device)

      -

    FILTER

    • Allergy Filter

      -

    • Antibacteria Micro Filter

      -

    • Dust Filter

      -

    • Fine Dust Filter

      -

    • Micro Filter

      -

    • Pre Filter

      -

    DESIGN

    • Color(Body)

      -

    • Color(Discharge)

      -

    • Display

      -

    COMPLIANCE

    • Installation Kit Model Name

      -

    • Launching Month (YYYY-MM)

      -

    • Manufacturer (Importer)

      -

    • Product Model Name

      -

    • Product Type & Model Name

      -

    HYGIENE

    • Auto Cleaning

      -

    • UV Nano

      -

    OUTDOOR UNIT

    • Outdoor Unit Model Name

      -

    EAN CODE

    • EAN CODE

      -
