- Wifi Smart control Capability*
- Corrosion Resistance Black Fin Coated
- Built In drain pump
- Two Thermistor Control
- Flexible Installation and Maintenance
All Spec
AEER / ACOP
AEER / ACOP
3.640 / 4.173
CAPACITY
Cooling (Min. ~ Rated ~ Max.) (kW) (T1)
2.50
Heating (Min. ~ Rated ~ Max.) (kW)
3.20
CONTINUOUS OPERATION
Cooling (°C (DB))
-15 ~ 48
Heating (°C (WB))
-18 ~ 18
CONVENIENCE
ThinQ(Wi-Fi)
Optional
FULL LOAD AMPS
Full Load Amps (A)
10.0
GENERAL
Indoor Unit Dimension_WxHxD(mm)
900 x 190 x 460
Indoor Unit Weight(kg)
18.0
Outdoor Unit Dimension_WxHxD(mm)
770 x 545 x 288
Outdoor Unit Weight(kg)
33.3
Refrigerant Type
R32
HEAT EXCHANGER
Corrosion Protection (Coating)
Black 2
Fin Type
Wide Louver Plus
INDOOR UNIT
Dimensions Net (W × H × D) (mm)
900 x 190 x 460
Fan Motor Type
BLDC
Net Weight (kg)
18.0
Power Supply (V, Ø, Hz)
1 , 50 Hz, 220-240 V
Sound Pressure Level Cooling (H / M / L) (dB(A))
- / 35.0 / 30.0 / 27.0
OUTDOOR UNIT
Compressor Type
Twin Rotary
Dimensions Net (W × H × D)(mm)
770 x 545 x 288
Drain Pipe(Natural Drainage) (mm(inch))
Ø 32(1-1/4)
Fan Motor Type
BLDC
Maximum Height Difference Outdoor Unit ~ Indoor Unit (Max.) (m (ft))
30
Net Weight (kg)
33.3
Piping Connections Gas (Outer Dia.) (mm (inch))
Φ9.52 (3/8)
Piping Connections Liquid (Outer Dia.) (mm (inch))
Φ6.35 (1/4)
Piping Length (Max.) (m)
30
Power Supply (V , Ø , Hz)
1 , 50 Hz, 220-240 V
Refrigerant Type
R32
Sound Pressure Level Cooling (Rated) (dB(A))
49
Sound Pressure Level Heating (Rated) (dB(A))
52
RATED CURRENT
Cooling (A)
3.00
Heating (A)
3.30
RETURN AIR OPENING
Supply (W x H, Flange) (mm)
148 x 860
SUPPLY AIR OPENING
Return (Oval) (mm)
190 x 807
