77” LG OLED TV B9 ThinQ AI

Specs

Reviews

Support

77” LG OLED TV B9 ThinQ AI

OLED77B9PUA

77” LG OLED TV B9 ThinQ AI

(3)
Print

All Spec

PICTURE(PANEL)

  • Display Type

    OLED

  • Display Resolution

    4K Ultra HD (3,840 x 2,160)

  • Wide Viewing Angle

    Yes

  • Dimming Technology

    Pixel Dimming

PICTURE(PROCESSING)

  • Picture Processor

    α7 Gen 2 Intelligent Processor

  • HDR (High Dynamic Range)

    4K Cinema HDR (Dolby Vision®, HDR10, HLG)
    HDR Dynamic Tone Mapping Pro

  • Contrast

    Object Depth Enhancer
    Ultra Luminance Pro

  • Clarity

    Quad Step Noise Reduction
    Frequency Based Sharpness Enhancer

  • Colour

    Intense Colour
    Billion Rich Colours
    Advanced Colour Enhancer
    True Colour Accuracy

  • Resolution Upscaler

    4K Upscaler

AI TV(ARTIFICIAL INTELLIGENCE)

  • LG ThinQ® AI

    Yes

  • Google Assistant

    Yes

  • Alexa Built-In

    Yes (Available via firmware update)

  • Google Home Compatible

    Yes (Google Home device sold separately)

  • Amazon Alexa Compatible

    Yes (Amazon Alexa device sold separately)

  • Intelligent Voice Recognition

    Yes

SMART TV

  • Operating System

    webOS®

  • Magic Remote Control

    Yes (Point, Click, Scroll, Voice)

  • Universal Remote Control

    Yes (Auto Device Detection)

  • LG Content Store (App Store)

    Yes

  • Full Web Browser

    Yes

AUDIO

  • Speaker System

    2.2 Channel

  • Output Power

    40W (20W Woofer)

  • Dolby Atmos

    Yes

  • WiSA Ready

    Yes (Separate Dongle Purchase Required)

  • DTS Decoder

    DTS-HD

  • Bluetooth Audio Playback

    Yes

  • LG Sound Sync

    Yes

CONNECTIVITY

  • Wi-Fi® Standard

    Wi-Fi Certified 802.11ac

  • Bluetooth® Support

    Version 5.0

  • IP Control

    Yes

  • HDMI-CEC (Simplink)

    Yes

  • TV Tuner

    ATSC, Clear QAM

  • Smart Phone Connectivity

    Yes

INPUTS & OUTPUTS

  • HDMI Input (HDCP 2.2)

    4 (1 rear, 3 side)

  • HDMI Audio Return Channel (ARC)

    eARC (HDMI 2)

  • USB Ports (v 2.0)

    3 (2 rear, 1 side)

  • RF Connection Input (Antenna/Cable)

    1 (rear)

  • Composite Input (AV)

    1 (rear)

  • Ethernet Input

    1 (rear)

  • RS-232C Input (Mini Jack)

    1 (rear)

  • Digital Audio Output (Optical)

    1 (rear)

POWER

  • Power Supply (Voltage, Hz)

    AC 120V, 50/60Hz

  • Standby Power Consumption

    Under 0.5W

  • Power Consumption

    170W

  • Annual Power Consumption

    313KWh/y

DIMENSIONS/WEIGHTS/UPC

  • TV Dimensions with Stand (WxHxD)

    1723 x 1043 x 270mm / 67.8” x 41.1” x 10.6”

  • TV Dimensions without Stand (WxHxD)

    1723 x 992 x 55.3mm / 67.8” x 39.1” x 2.2”

  • Packaging Dimensions (WxHxD)

    1895 x 1130 x 285mm / 74.6” x 44.5” x 11.2”

  • Stand Width

    749mm / 29.5”

  • TV Weight with Stand

    30kg / 66.1 lbs

  • TV Weight without Stand

    26.7kg / 58.9 lbs

  • Packaging Weight

    42.4kg / 93.5 lbs

  • VESA Mounting (W x H)

    400 x 200

  • UPC

    719192633735

ACCESSORIES INCLUDED

  • Remote Magic Remote

    Included

  • Remote Control Battery

    Yes

  • Power Cable

    Yes

  • Quick Start Guide

    Yes

  • E-Manual

    Yes

WARRANTY

  • Limited Warranty

    1 Year Parts & Labour

  • Model Year

    2019
