Product Type
Ceiling Concealed Duct
Inverter Technology
No
Indoor Unit Noise Level (H/M/L)
60 / -- / -- dB(A)
Refrigerant Type
R22
Operation Range
Up to 53°C
E.S.P
Yes
Energy saving (zero power consumption, standby mode)
Yes
Two Thermistors Control
Yes
Power Supply (Φ / V / Hz)
3/380~415/50
Cooling Capacity in TR
8.5
Power Input
9.1 kW
Air Flow Rate (H/M/L) (CFM)
3400
External Static Pressure
8 mmAq
Body Dimensions (W x H x D)
1,562 x 460 x 688 mm
Net Weight
90.0 kg
Compressor Type
Scroll
Sound Level (H)
68 dB(A)
Dimensions (W x H x D)
995 x 1,360 x 445 mm
Net Weight
140 kg
Piping Connections (Liquid)
Ø 15.88 mm
Piping Connections (gas)
Ø 34.93 mm
Drain (Outdoor / Indoor)
Ø 25.4 / 22.6 mm
Max. Piping Length (Main Piping)
30 m
Max. Elevation Difference (Indoor-Outdoor)
15 m
Residence
Yes
Retail Store
Yes
Restaurant
Yes
Office
Yes
Hospital
Yes
Hospitality
Yes
