Pixel Configuration
3 in 1 SMD
Pixel Pitch(mm)
3.906
Module Resolution (WxH)
64x64
Module Dimensions(WxH,mm)
250x250
Weight per Module (kg)
0.70
No. of Modules per Cabinet (WxH)
2 x 4
Cabinet Resolution (WxH)
128x256
Cabinet Dimensions (W x H x D, mm)
500x1000x68
Cabinet Surface Area (㎡)
0.500
Weight per Cabinet (kg/unit)
12.0
Weight per Square Meter (kg/㎡)
24.0
Physical Pixel Density (pixels/㎡)
65,536
Flatness of Cabinet (mm)
0.5
Cabinet Material
Die casting Aluminum
Service access
Front or Rear
Max Brightness (After Calibration, nit)
1,000
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
97%
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5000:1
Processing Depth (bit)
16(HDR10, HDR10 Pro)
Power Consumption (W/cabinet, Max.)
300
Power Consumption (W/cabinet, Avg.)
100
Power Consumption (W/㎡, Max.)
600
Heat Dissipation (BTU/h/Cabinet, Max.)
1,194
Heat Dissipation (BTU/h/Cabinet, Avg.)
396
Heat Dissipation (BTU/h/㎡, Max.)
2,388
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-20∘to +40∘
Operating Humidity
10-90%RH
IP rating Front
IP5X
IP rating Rear
IP5X
Certification
CE/FCC/cTUVus/CB/CCC
Environment
RoHS/REACH/WEEE
Controller
CVBA
90 Degree Corner Cut
Yes
