All Spec
PANEL
-
Screen Size (Inch)
-
55
-
Panel Technology
-
IPS
-
Back Light Type
-
Edge
-
Aspect Ratio
-
16:9
-
Native Resolution
-
3840 x 2160 (UHD)
-
Refresh Rate
-
60Hz
-
Brightness
-
700nit (Typ.)
-
Dynamic CR
-
1,000,000:1
-
Color Gamut
-
BT709 95%
-
Viewing Angle (H x V)
-
178 X 178
-
Color Depth (Number of Colors)
-
10bit(D), 1.07Billion colors
-
Response Time
-
8ms (G to G)
-
Surface Treatment (Haze)
-
28%
-
Life time
-
50,000Hrs (Min.)
-
Operation Hours (Hours/Day)
-
24/7
-
Portait / Landscape
-
Yes
CONNECTIVITY
-
HDMI In
-
Yes (2), 3840x2160@60Hz, HDCP 2.2/1.4
-
DP In
-
Yes (1), 3840x2160@60Hz, HDCP2.2/1.3
-
RS232C In
-
Yes (1)
-
RJ45(LAN) In
-
Yes (1)
-
IR In
-
Yes (1)
-
USB In
-
USB2.0 Type A(1), USB2.0 Type C ((1), without PD funtion)
-
DP Out
-
Yes (1), 3840x2160@60Hz, Input : HDMI1/2/DP/USB-C
-
Audio Out
-
Yes (1)
-
RS232C Out
-
Yes (1), 4pin Phone-jack
-
Daisy Chain
-
Yes (Input HDMI, DP, USB C / Output DP)
MECHANICAL SPECIFICATION
-
Bezel Color
-
Black
-
Bezel Width
-
T/R/L: 8.9mm, B: 12.9mm
-
Weight (Head)
-
16.1 kg
-
Packed Weight
-
20.5 kg
-
Monitor Dimensions (W x H x D)
-
1231.4 x 707.2 x 29.7mm (without IR)
-
VESA Standard Mount Interface
-
300 x 300
-
Carton Dimensions (W x H x D)
-
1360.0 x 801.0 x 161.0mm
FEATURE - HARDWARE
-
Internal Memory (eMMC)
-
16GB
-
Wi-Fi/BT (Built-in)
-
Yes
-
Temperature Sensor
-
Yes
-
Auto Brightness Sensor
-
Yes ( External IR)
-
Acceleration(Gyro) Sensor
-
Yes
-
Local Key Operation
-
Yes
FEATURE - SOFTWARE
-
OS Ver. (webOS)
-
webOS6.0
-
Local Contents Scheduling
-
Yes
-
Group Manager
-
Yes
-
USB Plug & Play
-
Yes
-
Fail Over
-
Yes
-
Booting Logo Image
-
Yes
-
No Signal Image
-
Yes
-
RS232C Sync
-
Yes
-
Local Network Sync
-
Yes
-
PIP
-
Yes
-
PBP
-
Yes (4)
-
Screen Share
-
Yes
-
Video Tag
-
Yes (4)
-
Play Via URL
-
Yes
-
Screen Rotation
-
Yes
-
External Input Rotation
-
Yes
-
Gapless Playback
-
Yes
-
Tile Mode Setting
-
Yes (Max. 15x15)
-
Setting Data Cloning
-
Yes
-
SNMP
-
Yes
-
ISM Method
-
Yes
-
Auto Set ID
-
Yes
-
Status Mailing
-
Yes
-
Control Manager
-
Yes
-
Cisco Certification
-
(TBD)
-
Crestron Connected
-
Yes
-
Smart Energy Saving
-
Yes
-
PM mode
-
Yes
-
Wake on LAN
-
Yes
-
Network Ready
-
Yes
-
BEACON
-
Yes
-
HDMI-CEC
-
Yes
-
SI Server Setting
-
Yes
-
webRTC
-
Yes
-
Pro:Idiom
-
Yes
ENVIRONMENT CONDITIONS
-
Operation Temperature
-
0 °C to 40 °C
-
Operation Humidity
-
10 % to 80 %
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-In Power
POWER CONSUMPTION
-
BTU (British Thermal Unit)
-
375 BTU/Hr(Typ.), 546 BTU/Hr(Max)
-
Smart Energy Saving (70%)
-
77
-
DPM
-
0.5W
-
Power off
-
0.5W
-
Max.
-
160W
-
Typ.
-
110W
SOUND
-
Speaker (Built-in)
-
Yes (10W X 2)
CERTIFICATION
-
Safety
-
CB / NRTL
-
EMC
-
FCC Class "B" / CE / KC
-
ERP / Energy Star
-
Yes (NewErP)/Yes
-
ePEAT(US only)
-
Yes
SOFTWARE COMPATIBILITY
-
SuperSign CMS
-
Yes
-
SuperSign Control+
-
Yes
-
SuperSign WB
-
Yes
-
SuperSign Cloud
-
Yes
-
Promota
-
Yes (Not available for EU/CIS)
-
Mobile CMS
-
Yes
-
Connected Care
-
Yes
LANGUAGE
-
OSD
-
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic
ACCESSORY
-
Basic
-
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, USB-C Cable, Cable Holder(2EA), AC Cord Holder (1EA)
-
Optional
-
Slim Wall Mount (WB21LMA/B), 일반 Wall Mount (OLW480A/B) Wall Mount Adapter (AM-B330S)
SPECIAL FEATURE
-
Tilt (Face up)
-
Yes (Max 30˚ degree, 40℃ temperature)
-
IP Rating
-
IP5X
-
Conformal Coating (Power Board)
-
Yes
