- Resolution : 3,840 × 2,160 (UHD)
- Brightness : 500 nits (Typ.)
- Surface Treatment (Haze) : 25%
- Bezel : 12.9 mm (Even)
All Spec
PANEL
Screen Size
190.5 cm (75)
Panel Technology
ADS
Back Light Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60 Hz
Brightness
500 cd/m² (500 nits)
Dynamic CR
1,000,000:1
Color Gamut
BT709 95%
Viewing Angle (H x V)
178 X 178
Color Depth (Number of Colors)
1.07G (8bits + FRC)
Response Time
8 ms ( G to G)
Surface Treatment (Haze)
25%
Operation Hours (Hours/Day)
24/7
Portait / Landscape
Yes / Yes
CONNECTIVITY
HDMI In
Yes(3)
HDMI In (HDCP Ver.)
3840x2160@60Hz, HDCP 2.2/1.4
DP In
3840x2160@60Hz, HDCP 2.2/1.3
RS232C In
Yes(1), 4pin Phone-jack
RJ45(LAN) In
Yes(1)
IR In
Yes(1)
USB In
USB2.0 Type A(2)
Audio Out
Yes(1)
RS232C Out
Yes(1), 4pin Phone-jack
MECHANICAL SPECIFICATION
Bezel Color
Black
Bezel Width
12.9 mm (Even)
Weight (Head)
35.7 kg
Packed Weight
44 kg
Monitor Dimensions (W x H x D)
1679.5 x 958.7 x 29.7 mm (without IR, Handle)
VESA Standard Mount Interface
600 x 400
Carton Dimensions (W x H x D)
1820 x 1115 x 200 mm
FEATURE - HARDWARE
Internal Memory (eMMC)
16 GB
Wi-Fi/BT (Built-in)
Yes
Temperature Sensor
Yes
Auto Brightness Sensor
Yes(IR)
Acceleration(Gyro) Sensor
Yes
Local Key Operation
Yes
FEATURE - SOFTWARE
OS Ver. (webOS)
webOS6.0
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail Over
Yes
Booting Logo Image
Yes
No Signal Image
Yes
RS232C Sync
Yes
Local Network Sync
Yes
PIP
Yes
PBP
Yes(4)
Screen Share
Yes
Video Tag
Yes(4)
Play Via URL
Yes
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes (Max. 15x15)
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Cisco Certification
Yes
Crestron Connected
Yes
Smart Energy Saving
Yes
PM mode
Yes
Wake on LAN
Yes
Network Ready
Yes
BEACON
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
Pro:Idiom
Yes
ENVIRONMENT CONDITIONS
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
POWER
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
POWER CONSUMPTION
BTU (British Thermal Unit)
546 BTU/Hr(Typ.), 819 BTU/Hr(Max)
Smart Energy Saving (70%)
112 W
DPM
0.5 W
Power off
0.5 W
Max.
240 W
Typ.
160 W
SOUND
Speaker (Built-in)
Yes (10 W X 2)
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class "B" / CE / KC
ERP / Energy Star
NA/Yes
ePEAT(US only)
Yes (Carbon Measured)
SOFTWARE COMPATIBILITY
SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign WB
Yes
SuperSign Cloud
Yes
Mobile CMS
Yes
Connected Care
Yes
LANGUAGE
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic
ACCESSORY
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6ea)
Optional
Wall Mount (LSW640A/B)
SPECIAL FEATURE
IP Rating
IP5X
Conformal Coating (Power Board)
Yes (Partial Space Coating)
