A man is looking at a big screen attached to the window of a sports store.
* All images in this web page are for illustrative purposes only.
* The "LG Conventional" refers to displays which do not include an image improvement algorithm.
* Results based on in-house testing. Actual test results may differ depending on environment and measuring equipment.
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic
OPS Type compatible
NO
OPS Power Built-in
NO
Power Supply
AC 100-240 V~, 50/60 Hz
Power Type
Built-in Power
Speaker (Built-in)
NO
Basic
Remote Controller(include battery 2 ea), Power Cord, RS232C cable, DP cable, IR Receiver, Guide Bracket, Screws, Manual
Optional
NO
Smart Calibration
N/A
Conformal Coating (Power Board)
YES
Direct Sunlight
N/A
IP Rating
IP5X tested
Overlay Touch Compatibility
N/A
Power Protection
N/A
Tilt (Face down)
N/A
Tilt (Face up)
N/A
Operation Humidity
10 % to 80 %
Operation Temperature
0 °C to 40 °C
Wi-Fi/BT (Built-in)
NO
Acceleration (Gyro) Sensor
NO
Auto Brightness Sensor
NO
BLU Sensor
NO
Current Sensor
NO
FAN (Built-in)
NO
Humidity Sensor
NO
Internal Memory (eMMC)
NO
Local Key Operation
NO
Pixel Sensor
NO
Power Indicator
NO
Proximity Sensor
NO
Temperature Sensor
YES
ERP / Energy Star
YES / Energy Star 8.0(US Only)
EMC
FCC Class "A" / CE / KC
ePEAT(US only)
NO
Safety
CB / NRTL
Connected Care
NO
Mobile CMS
NO
SuperSign Cloud
NO
SuperSign CMS
YES
SuperSign Control+
YES
SuperSign WB
YES
RJ45(LAN) In
YES (1 ea)
Audio In
YES
Audio Out
YES
Daisy Chain
Input : HDMI, DP, DVI-D / Output : DP
DP In
YES (HDCP 1.3)
DP Out
YES
DVI-D In
YES (HDCP 1.4)
External Speaker Out
NO
HDMI In
YES (2 ea)
HDMI In (HDCP Ver.)
1.4
HDMI Out
NO
IR In
YES
IR Out
NO
RGB In
NO
RJ45(LAN) Out
NO
RS232C In
YES
RS232C Out
YES
Touch USB
NO
USB In
USB 2.0 Type A (1 ea)
VESA™ Standard Mount Interface (mm)
600 x 400 mm
Bezel Color
Black
Bezel Width
T/R/L/B : 2.25/1.25/2.25/1.25 mm
Carton Dimensions (W x H x D, mm)
1214 x 778 x 263 mm
Handle
YES
Monitor Dimension (W x H x D, mm)
1077.6 x 607.8 x 89.7 mm
Monitor Dimension with Stand (W x H x D)
N/A
Packed Weight
21.9 Kg
Weight (Head)
16.9 Kg
Weight (Head+Stand)
N/A
Color Depth (Number of Colors)
1.07 Billion colors
Aspect Ratio
16:9
Back Light Type
Direct
Brightness
500 nit (Typ.)
Color Gamut
NTSC 72 %
Dynamic CR
500,000:1
Native Resolution
1920 x 1080 (FHD)
Operation Hours (Hours/Day)
24/7
Panel Technology
IPS
Portait / Landscape
YES / YES
QWP (Quarter Wave Plate)
N/A
Refresh Rate
60 Hz
Response Time
8 ms (G to G)
Screen Size
124.46 CM (49)
Surface Treatment (Haze)
Haze 3 %
Transparency
N/A
Viewing Angle (H x V)
178 º x 178 º
Scan Inversion
YES
Auto Set ID
YES
Backlight Sync
NO
BEACON
NO
Booting Logo Image
YES
Brightness Compensation
NO
Cisco Certification
NO
Control Manager
NO
Crestron Connected
YES
External Input Rotation
NO
Fail Over
YES
Gapless Playback
NO
Group Manager
NO
HDMI-CEC
YES
ISM Method
YES
Local Contents Scheduling
YES
Local Network Sync
NO
Network Ready
NO
No Signal Image
YES
OS Ver. (webOS)
Non-webOS
PBP
NO
PIP
NO
Play Via URL
NO
PM mode
YES
Pro:Idiom
NO
RS232C Sync
YES
Screen Rotation
YES
Screen Share
NO
Setting Data Cloning
YES
SI Server Setting
NO
Smart Energy Saving
YES
SNMP
YES
Status Mailing
NO
Tile Mode Setting
YES
USB Plug & Play
YES
Video Tag
NO
Wake on LAN
YES
webRTC
NO
W/B Setting by Grey scale
YES
Others-BTU (British Thermal Unit)
341 BTU/Hr(Typ.), 409 BTU/Hr(Max.)
DPM
0.5 W
Max.
120 W
Power off
0.5 W
Smart Energy Saving (70%)
60 W
Typ.
100 W
