All Spec
PANEL
-
Screen Size
-
139.7cm (55)
-
Panel Technology
-
OLED
-
Native Resolution
-
1,920 x 1,080 (FHD)
-
Brightness (Typ., nit, APL 100%, Without Glass)
-
150
-
Brightness (Typ., nit, APL 25%, without Glass)
-
400
-
Contrast Ratio
-
150,000 : 1
-
Color Gamut
-
BT709 120 %
-
Viewing Angle (H x V)
-
178 x 178
-
Color Depth
-
1.07 Billion Colors (10 bit)
-
Response Time
-
1 ms (G to G)
-
Surface Treatment (Haze)
-
Hard coating (2H)
-
Operation Hours (Hours / Day)
-
18 / 7 (Moving Content Only)
-
Portrait / Landscape
-
Yes / Yes
-
Transparency (Typ.)
-
33% (Set)
CONNECTIVITY
-
Input
-
HDMI (HDCP 2.2), DP (HDCP 1.3), USB 2.0 Type A, USB 2.0 Type A (Touch Control Board Only)
-
Output
-
DP, Audio, USB 2.0 Type B (Touch USB)
-
External Control
-
RS232C In/Out, RJ45 (LAN) In/Out, IR In (External IR Receiver)
MECHANICAL SPECIFICATION
-
Bezel Color
-
Matt Silver
-
Bezel Width
-
7.9 / 7.9 / 7.9 / 144.5 mm (T / R / L / B)
-
Weight (Head)
-
(Head) 14.6 kg
(Signage Box) 3.4 kg
-
Monitor Dimension (W x H x D)
-
(Head) 1,225.5 x 832.9 x 7.0 mm
(Signage Box) 782.8 x 238.4 x 34.7 mm
-
Protection Glass
-
Depth 3.0 mm , Tempered / Chemical Strengthening, Anti-Reflective, Shatter-Proof
FEATURE
-
Key Feature
-
Internal Memory (16GB), Temperature Sensor, FAN, webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Video Tag (4), Rotation (Screen Rotation), Gapless Playback, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Connected®(Network based control), PM Mode, Wake on LAN, HDMI-CEC(Compatibility may differ by equipment.), SI Server Setting, Pro:Idiom
ENVIRONMENT CONDITIONS
-
Operation Temperature Range
-
0°C to 40°C
-
Operation Humidity Range
-
10% to 80%
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-in Power
POWER CONSUMPTION
-
Typ. / Max.
-
250 W / 280 W
-
BTU (British Thermal Unit)
-
853 BTU/Hr (Typ.), 955 BTU/Hr (Max.)
CERTIFICATION
-
Safety
-
CB / NRTL
-
EMC
-
FCC Class "A" / CE / KC
-
ErP
-
Yes (EU Only)
SOFTWARE COMPATIBILITY
-
SuperSign CMS
-
Yes
-
SuperSign Control / Control+
-
Yes
-
SuperSign Media Editor
-
Yes
-
Signage365Care
-
Yes (The availability can differ by region.)
ACCESSORY
-
Basic
-
Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, FFC Cables (1,600 mm × 4 ea for Connection Between Panel and Signage Box), HDMI Cable (3 M), Micro to A Type USB Cable (1.8 M for Connection Between Touch and Signage Box), A to B Type USB Cable (Touch Out), Tape (10 ea for Cabling / 10 ea EMI Gasket Tape), Screw (M4 × L22, 12 ea / M4 Nut 12 ea / M3 × L5.5, 8 ea / M3 × L3.5, 20 ea), Shield Cover Ass'y, Rubber Damper 4 ea, Touch Cable Holder 2 ea
