Outdoor LED
Contact Us

Outdoor Signage for
Medium-Range Attraction

Engage Passersby with Eye-Catching Displays.
A large LED screen is installed on the exterior wall of the building entrance. Even in strong sunlight, the screen’s content is clearly visible. A large LED screen is installed on the exterior wall of the building entrance. Even in strong sunlight, the screen’s content is clearly visible.
* All images in this page are for illustrative purposes only.
A large GSPB screen is installed on the exterior wall of a low-rise building. A large GSPB screen is installed on the exterior wall of a low-rise building.

Medium-Range Attraction

Designed for medium-range applications, the GSPB series model excels at drawing attention from a moderate distance. Perfect for shopping malls and low-rise building exteriors, it ensures your message is seen with just a glance upward.
The GSPB series, with its enhanced power consumption, offers higher energy efficiency. The GSPB series, with its enhanced power consumption, offers higher energy efficiency.

Enhanced Energy Efficiency

Compared to LG’s previous standard model, the brightness has increased by 3,000 nits while maintaining slightly lower power consumption levels. This means that the display is both brighter and more energy-efficient, which can help save on operating costs.

* The comparison is with the GSCD39-KK model. GSCD039-KK : 660 W/sqm, GSPB039-CA : 630 W/sqm
The use of two cabinet sizes and an L-shaped installation enables the LED screen to be seamlessly mounted on the building's cornered wall. The use of two cabinet sizes and an L-shaped installation enables the LED screen to be seamlessly mounted on the building's cornered wall.

Flexible Installation

The GSPB series offers two sizes of cabinets, allowing for a screen size configuration that perfectly meets customer demands. Both side-cut cabinets can also be used as described. The GSPB series integrates seamlessly into the space and delivers smooth content to customers.
In the strong sunlight, a common outdoor signage screen becomes blurred by light and cannot be seen clearly, while the 8,000 nits LED screen remains clearly visible. In the strong sunlight, a common outdoor signage screen becomes blurred by light and cannot be seen clearly, while the 8,000 nits LED screen remains clearly visible.

High Brightness for Outdoor

With a great brightness of 8,000 nits, it clearly delivers content and attracts public attention, which is the suitable display for outdoor visibility.

Compatibility with LG Software Solutions

When connected with LG’s CVCA / CBCA system controller, the GSPB series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
The LG employee is remotely monitoring the GSPB series installed in a different place by using a cloud-based LG monitoring solution. The system controller with webOS enables the GSPB series to be compatible with LG software solutions. The LG employee is remotely monitoring the GSPB series installed in a different place by using a cloud-based LG monitoring solution. The system controller with webOS enables the GSPB series to be compatible with LG software solutions.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
* Actual GUI may vary in different webOS versions.
* LG Software solutions needs to be purchased separately.
Close
Physical Parameters
  • Pixel Configuration
    Single SMD
    Pixel Pitch(mm)
    3.91
  • Module Resolution (WxH)
    128x64
    Module Dimensions(WxH,mm)
    500x250
  • Weight per Module (kg)
    1.6
    No. of Modules per Cabinet (WxH)
    2 x 4
  • Cabinet Resolution (WxH)
    256x256
    Cabinet Dimensions (W x H x D, mm)
    1,000 x 1,000 x 87
  • Cabinet Surface Area (m²)
    1
    Weight per Cabinet (kg/unit)
    23
  • Weight per Square Meter (kg/m²)
    23
    Physical Pixel Density (pixels/m²)
    65,536
  • Flatness of Cabinet (mm)
    ±0.5
    Cabinet Material
    Aluminum
  • Service Access
    Front & Rear
OPTICAL SPECIFICATIONS
  • Brightness (After Calibration, nit)
    Max. 8,000
    Color Temperature (K)
    3,200 ~ 9,300
  • Visual Viewing Angle (Horizontal)
    160
    Visual Viewing Angle (Vertical)
    150
  • Brightness Uniformity
    0.97
    Color Uniformity
    ±0.003Cx,Cy
  • Contrast Ratio
    20,000:1
    Processing Depth (bit)
    16 (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
  • Power Consumption (W/Cabinet, Max.)
    630
    Power Consumption (W/Cabinet, Avg.)
    210
  • Power Consumption (W/m², Max.)
    630
    Heat Dissipation (BTU/h/Cabinet, Max.)
    2,150
  • Heat Dissipation (BTU/h/Cabinet, Avg.)
    717
    Heat Dissipation (BTU/h/m², Max.)
    2,150
  • Power Supply (V)
    100 to 240
    Frame Rate (Hz)
    50 / 60
  • Refresh Rate (Hz)
    7,680
OPERATION SPECIFICATIONS
  • LED Lifetime (Half brightness)
    100,000
    Operating Temperature(℃)
    -30°C to +50°C
  • Operating Humidity
    10~99%RH
    IP Rating Front
    IP65
  • IP Rating Rear
    IP65
Standard
  • Certification
    CE, ETL, FCC, CB(TBD), BIS(TBD), KC (TBD) EMC Class A
    Certification (Fire Protection)
    BS476 Part7 Class2
    & EN13501-1 Class B
Environment
  • Environment
    RoHS, REACH
Controller
  • Controller
    CVCA / CBCA / LCIN

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
