Slim Bezel Video Wall

55VL5PJ

Key Features

Brightness(Typ.) : 500 nit
Bezel : 2.25 mm (T/L), 1.25 mm (B/R)
Depth : 93.1 mm
Interface : HDMI/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR

A man is looking at a big screen attached to the window of a sports store.

* All images in this web page are for illustrative purposes only.

Daisy Chain Capability

By using this daisy-chained network feature, you can execute commands such as controlling, monitoring and even updating firmware.

Multiple displays are being managed simultaneously through the daisy chain. The UHD daisy chain utilizing HDMI and DisplayPort allows easy access to adjusting UHD settings.

Real-Time LG ConnectedCare

Maintenance is easy and fast with the optional LG ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.

The LG employee is remotely monitoring the VL5PJ installed in a different place by using cloud-based LG monitoring solution.

* LG ConnectedCare is the brand name of LG Signage365Care Service. The availability differs by region.

Ultra Narrow Bezel

The 3.5mm ultra narrow bezel size creates immersive and seamless viewing experiences on assembled video wall screens.

Easy Color Adjustment

Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.

Image Gap Reduction

The VL5PJ includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.

* The "LG Conventional" refers to displays which do not include an image improvement algorithm.
** The image shown above are for illustration purposes only.

High Performance and Great Scalability

Thanks to its built-in SoC and webOS smart signage platform, the VL5PJ can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a web-based platform and offers SDK (Software Development Kit), it is even easier for SIs to build and optimize their web apps.

* SDK can be downloaded with the link below. (https://webossignage.developer.lge.com)

All Spec

PANEL

Screen Size
139.7 cm (55)
Panel Technology
IPS
Back Light Type
Direct
Aspect Ratio
16:09
Native Resolution
1920 x 1080
Refresh Rate
60Hz
Brightness
500nit (Typ.)
Contrast Ratio
1,200:1
Dynamic CR
500,000:1
Color Gamut
NTSC 72%
Viewing Angle (H x V)
178 X 178
Color Depth (Number of Colors)
10bit, 1.07Billion colors
Response Time
8ms(G to G)
Surface Treatment (Haze)
3%
Life time
60,000Hrs (Typ.)
Operation Hours (Hours/Day)
24/7
Portait / Landscape
Yes / Yes

CONNECTIVITY

HDMI In
2
HDMI In (HDCP Ver.)
2.2
DP In
1 (HDCP 2.2)
DVI-D In
1 (HDCP 1.4)
Audio In
1
RS232C In
1
RJ45(LAN) In
1
IR In
1
USB In
USB2.0 Type A(1)
DP Out
1, Input : HDMI / DVI / DP
Audio Out
Yes(1)
RS232C Out
Yes(1)
Daisy Chain
Yes(Input HDMI, DP, DVI / Output DP)

MECHANICAL SPECIFICATION

Bezel Color
Black
Bezel Width
T/R/L/B : 2.25/1.25/2.25/1.25mm
Weight (Head)
23.5Kg
Packed Weight
26.9Kg
Monitor Dimensions (W x H x D)
1213.4 x 684.2 x 93.1mm
Handle
Yes
VESA Standard Mount Interface
600 x 400
Carton Dimensions (W x H x D)
1353 x 855 x 263mm

FEATURE - HARDWARE

Internal Memory (eMMC)
8GB
Temperature Sensor
Yes
Acceleration(Gyro) Sensor
Yes

FEATURE - SOFTWARE

OS Ver. (webOS)
webOS
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail Over
Yes
No Signal Image
Yes
RS232C Sync
Yes
Local Network Sync
Yes
Video Tag
Yes(4)
Play Via URL
Yes
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes(Max. 15x15)
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Crestron Connected
Yes
Smart Energy Saving
Yes
PM mode
Yes
Wake on LAN
Yes
Network Ready
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
Pro:Idiom
Yes
W/B Setting by Grey scale
Yes
Scan Inversion
Yes

ENVIRONMENT CONDITIONS

Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %

POWER

Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power

POWER CONSUMPTION

BTU (British Thermal Unit)
461 BTU/Hr(Typ.)
Smart Energy Saving (70%)
80W
DPM
0.5W
Power off
0.5W
Typ.
135W

CERTIFICATION

Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
Yes / Energy Star 8.0

SOFTWARE COMPATIBILITY

SuperSign CMS
Yes
SuperSign WB
Yes
Connected Care
Yes

LANGUAGE

OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic
