Cabinet material
Aluminum
Flatness of Cabinet (mm)
±0.15
Module Dimensions(WxH,mm)
300*168.75
Module Resolution (WxH)
160*90
No. of Modules per Screen (WxH)
12x12 (Total 144)
Physical Pixel Density (pixels/㎡)
284444
Pixel Configuration
3 IN 1 SMD
Pixel Pitch (mm)
1.88
Screen Dimensions (W x H x D, mm, including bezel)
3,605 X 2030 X 29.95 (Thickest 59.5)
Screen Resolution (WxH)
1920 x 1080
Screen Surface Area (㎡)
7.29
Service access
Front
Unit Case material
Aluminum
Weight of the screen
155
Brightness Uniformity(%)
98%
Color Temperature (K)
3,200~9,300
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000:1
Max Brightness (After Calibration, nit)
Typ. 500
Processing Depth (bit)
16
Visual Viewing Angle (Horizontal)
150
Visual Viewing Angle (Vertical)
150
Frame Rate (Hz)
50 / 60
Heat Dissipation (BTU/h/Screen, Avg.)
2,560
Heat Dissipation (BTU/h/Screen, Max.)
6,825
Power Consumption (W/㎡, Max.)
275
Power Consumption (W/Screen, Avg.)
750
Power Consumption (W/Screen, Max.)
2000
Power Supply (V)
100 to 240
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
IP rating Front
IP30
IP rating Rear
IP30
Operating Humidity
10~90%RH
Operating Temperature(℃)
0℃ to +40℃
Certification
CE,FCC,ETL,CB,CE-RED EMC Class A
Cinema server compatibility
BS476: Part7 Class 1 EN13501-1 (Class B-s1,d0)
Speaker
Built-in(9W+9W)
Environment
RoHS, REACH
Controller
Embedded(webOS)
Model name
LAPA163
I/O Port
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Digital Audio Out (1, SPDIF Optical)
