Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.25
Module Resolution (W x H)
120 × 270
Module Dimensions (W x H, mm)
150 × 337.5
Weight per Module (kg)
0.50
No. of Modules per Cabinet (W × H)
4 × 1
Cabinet Resolution (W × H)
480 × 270
Cabinet Dimensions (W × H × D, mm)
600 × 337.5 × 56
Cabinet Surface Area (m²)
0.203
Weight per Square Meter (kg/m²)
30.0
Weight per Cabinet (kg/cabinet)
6.0
Physical Pixel Density (pixels/m²)
640,000
Flatness of Cabinet
0.5
Cabinet Material
Die Casting Aluminum
Service Access
Front
Max. Brightness (After Calibration)
600
Color Temperature
3,200-9,300
Visual Viewing Angle (Horizontal/Vertical)
160 × 140
Brightness Uniformity
97%
Color Uniformity
±0.003 Cx,Cy
Contrast Ratio
5,000 : 1 (Typ.)
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Power Consumption (W/cabinet, Max.)
120
Power Consumption (W/cabinet, Avg.)
40
Power Consumption (W/m², Max.)
600
Power Consumption (BTU/Cabinet, Max.)
409
Power Consumption (BTU/Cabinet, Avg.)
136
Power Consumption (BTU/㎡, Max.)
2,047
Power Supply (V)
AC 100-240 V (50-60 Hz)
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature (°C)
-20 to +40
Operating Humidity
10-80% RH
IP rating Front / Rear
IP5X / IP5X
