Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.56
Module Resolution (WxH)
192x216
Module Dimensions(WxH,mm)
300x337.5x13
Weight per Module (kg)
0.95
No. of Modules per Cabinet (WxH)
4x2
Cabinet Resolution (WxH)
768x432
Cabinet Dimensions (W x H x D, mm)
1,200x675x72
Cabinet Surface Area (㎡)
0.81
Weight per Cabinet (kg/unit)
23
Weight per Square Meter (kg/㎡)
28
Physical Pixel Density (pixels/㎡)
409,600
Flatness of Cabinet (mm)
±0.3
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
600
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
150
Brightness Uniformity(%)
0.97
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14
Refresh Rate (@24Hz)
3,840
Life Time (Brightness 50%)
100,000
Power Consumption (W/Cabinet, Max.)
428
Power Consumption (W/Cabinet, Avg.)
182
Power Consumption (W/㎡, Max.)
530
Heat Dissipation (BTU/h/Cabinet, Max.)
1,460
Heat Dissipation (BTU/h/Cabinet, Avg.)
621
Heat Dissipation (BTU/h/㎡, Max.)
1,808
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Operating Temperature(℃)
-20℃ to +40℃
Operating Humidity
10~80%RH
IP rating Front
IP50
IP rating Rear
IP50
Certification
CE (EMC), FCC, cTUVus, CB, CE,
Environment
RoHS, REACH
Controller
CVBA
