Certification
CE, FCC, cTUVus, CB, KC, CCC, Class C
90 degree corner cut
Yes
Controller
CVBA
Frame Rate (Hz)
50 / 60
Heat Dissipation (BTU/h/Cabinet, Avg.)
174
Heat Dissipation (BTU/h/Cabinet, Max.)
400
Heat Dissipation (BTU/h/㎡, Max.)
1,980
Power Consumption (W/Cabinet, Avg.)
51
Power Consumption (W/Cabinet, Max.)
117
Power Consumption (W/㎡, Max.)
580
Power Supply (V)
100 to 240
Refresh Rate (Hz)
3,840
Environment
RoHS, REACH
LED Lifetime (Half brightness)
100,000
IP rating Front
IP50
IP rating Rear
IP50
Operating Humidity
10~80%RH
Operating Temperature(℃)
-20℃ to +40℃
Brightness Uniformity(%)
97
Color Temperature (K)
3,200~9,300
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Max Brightness (After Calibration, nit)
600
Processing Depth (bit)
14
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
150
Cabinet Dimensions (W x H x D, mm)
600x337.5x72
Cabinet material
Die-casting Aluminum
Cabinet Resolution (WxH)
480x270
Cabinet Surface Area (㎡)
0.2
Flatness of Cabinet (mm)
±0.3
Module Dimensions(WxH,mm)
300x337.5x13
Module Resolution (WxH)
240 x 270
No. of Modules per Cabinet (WxH)
2x1
Physical Pixel Density (pixels/㎡)
640,000
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.25
Service access
Front
Weight per Cabinet (kg/unit)
6.5
Weight per Module (kg)
0.95
Weight per Square Meter (kg/㎡)
32.0
