Cabinet Dimensions (W x H x D, mm)
1,000x1,000x86.4
Cabinet material
Extrusion Aluminum
Cabinet Resolution (WxH)
256x256
Cabinet Surface Area (㎡)
1
Flatness of Cabinet (mm)
±0.5
Module Dimensions(WxH,mm)
500x250
Module Resolution (WxH)
128x64
No. of Modules per Cabinet (WxH)
2x4
Physical Pixel Density (pixels/㎡)
65,536
Pixel Configuration
Single SMD
Pixel Pitch (mm)
3.91
Service access
Front or Rear
(select one only)
Weight per Cabinet (kg/unit)
19.5
Weight per Module (kg)
1.35
Weight per Square Meter (kg/㎡)
19.5
Brightness Uniformity(%)
0.97
Color Temperature (K)
3,200~9,000
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
6,000:1
Max Brightness (After Calibration, nit)
5,000
Processing Depth (bit)
14
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
153
Frame Rate (Hz)
50 / 60
Heat Dissipation (BTU/h/Cabinet, Avg.)
751
Heat Dissipation (BTU/h/Cabinet, Max.)
2,252
Heat Dissipation (BTU/h/㎡, Max.)
2,252
Power Consumption (W/Cabinet, Avg.)
220
Power Consumption (W/Cabinet, Max.)
660
Power Consumption (W/㎡, Max.)
660
Power Supply (V)
100 to 240
Refresh Rate (Hz)
3,840
IP rating Front
IP65
IP rating Rear
IP65
Operating Humidity
10~99%RH
Operating Temperature(℃)
-30°C to +50°C
Certification
CE, FCC, ETL
Environment
RoHS
Controller
CVCA
90 degree corner cut
Yes
Model name
GSCD039
