- 140㎛ pixel size
- 16bit A/D conversion
- IP68, Magnesium & Carbon-fiber Body
- Raw Image in 1.5 sec.(Wired) / 2 sec.(Wireless)
- Max. Uniform Load : 400kg / Max. Point Load : 200kg
All Spec
SPECIFICATION
-
Intended Use
-
General Radiography
-
TFT Type
-
A-si
-
Scintillator
-
CsI
-
Pixel Pitch
-
140 ㎛
-
A/D Conversion
-
16bit
-
Data Output
-
16bit
-
Cycle Time
-
4.5 sec (Wired) / 5 sec (Wireless)
-
Full Image Transfer (Typical) *Without window time
-
1.5 sec (Wired) / 2 sec (Wireless)
-
FDA 510(k) Clearance
-
K221394
IMAGE AREA
-
X-ray Sensitive Pixel
-
2500 x 3052 pixels
-
TFT Active Area
-
358.40 x 430.08 mm
MTF
-
MTF @ 0.5lp/mm (Typical)
-
84%
COMMUNICATION
-
Type
-
Wired / Wireless
-
WLAN
-
IEEE802.11a/b/g/n/ac, 2.4GHz/5GHz
-
Auto Exposure Detection
-
Yes
DURABILITY
-
Maximum Load Weight
-
Full (Uniform Load) : 400 kg (881.8 lbs) , Local (Point Load) : 200 kg (440.9 lbs)
-
Water-Resistant
-
IP68
-
Sensor Protection Plate
-
Carbon Fiber Plate
BATTERY
-
Operating Time
-
300 shots / 7.5 hrs (Typical) (Condition : Cycle Time 90 sec)
-
Charging Time
-
3 hrs (Type)
-
Hot Swap
-
Yes (1 Min)
ACCESSORIES
-
Cable
-
Power Cord, Main Cable 7 m (LAN Cable, Sync Cable Option)
-
Other
-
Battery Charger, 2 x Battery Packs, Control Box
