Category
Surgical Monitors
Aspect Ratio
16:9
Backlight Dimming Technology
Global Dimming
Backlight Technology
LED
Backlight Type
Edge
Brightness (Min.)
650cd/m²
Brightness (Typ.)
800cd/m²
Brightness (Stabilization)
500cd/m²
Color Bit
10bit
Color Depth (Number of Colors)
1.07B
Color Gamut (Typ.)
sRGB 115% (Area),sRGB over 99% (Coverage)
Contrast Ratio (Typ.)
1300:1
Contrast Ratio with DFC
Mega
Panel Type
IPS
Peak Brightness (Min.)
650cd/m² (Peak)
Peak Brightness (Typ.)
800cd/m² (Peak)
Pixel Pitch (H x V)
0.18159mm x 0.18159mm
Resolution
3840 x 2160
Response Time (GTG)
14ms (Off-setting), 5ms (Faster-setting)
Size (cm)
80.01cm (31.5)
Surface Treatment
Protection Glass (1.6t, Anti-Reflection, Anti-fingerprint)
Viewing Angle (CR≥10)
178°(Right/Left), 178°(Up/Down)
Dimension in Shiping (W x H x D)
883 x 599 x 200 mm
Dimension with Stand (W x H x D)
No Stand
Dimension without Stand (W x H x D)
764.6 x 480.8 x 94.4 mm
Pallet Stuffing (20ft/40ft/40ft HC)
216EA/405EA/495EA
Weight in Shipping
18.5kg
Weight with Stand
No Stand
Weight without Stand
13.5kg
Time/years
3
Time/years
3 (10,000hr)
Adapter
Yes
Adapter (Color)
White
Calibration Report (Paper)
Yes
Display Port
Yes
Display Port (Color/Length)
Black/1.8m
HDMI
Yes
HDMI (Color/Length)
Black/1.8m
Power Cord
Yes
Power Cord (Color/Length)
White/1.5m
3G-SDI
Yes (12G INx1/OUTx1,Single, 2SI, Square, SFP)
12G-SDI
Yes (12G INx1/OUTx1,Single, 2SI, Square, SFP)
DisplayPort
Yes (in 1ea/out 1ea)
DP (HDCP Version)
2.2
DP (Max. Resolution at Hz)
3840 x 2160 at 60Hz
DP (H-Frequency)
30~135kHz
DP (V Frequency)
56~61Hz
DP Version
1.2
DVI
Yes (1In / 1Out)
DVI (Max Resolution at Hz)
1920 x 1080 at 60Hz
DVI (H Frequency)
30~83kHz
DVI (V Frequency)
56~61Hz
HDMI
Yes (1ea)
HDMI (HDCP Version)
2.2
HDMI (Max. Resolution at Hz)
3840 x 2160 at 60Hz
HDMI (H Frequency)
30~135kHz
HDMI (V Frequency)
56~61Hz
HDMI Version
2.0
RS-232
Yes (1ea)
USB Downstream Port
Yes (1ea/ver2.0)
USB Upstream Port
Yes (1ea/ver2.0)
[Location]
Bottom
True Color Pro
Yes
Borderless Design
Normal
Color (Back Cover)
White
Color (Middle Cabinet)
Silver
Display Position Adjustments
No Stand
Down Height
No Stand
Height Range
No Stand
Mechanical Power Switch
Yes
OneClick Stand
No Stand
Pivot
No Stand
Swivel
No Stand
Tilt
No Stand
Wall Mount Size
200 x 100mm/100 x 100mm
IEC (IEC 60601-1 / IEC 60601-1-2)
Yes
EN (EN 60601-1 / EN 60601-1-2)
Yes
IEC (IEC 60950-1 / IEC 55032, 55024)
Yes
EN (EN 60950-1 / EN 55032, 55024)
Yes
cUL (ANSI/AAMI ES 60601-1, CSA CAN/CSA-C22.2 NO. 60601-1)
Yes
FCC (FCC part 15 Class A)
Yes
FDA
Registration (Class I)
ISO13485
Yes
GMP
Yes
KGMP
Yes
RoHS
Yes
REACH
Yes
WEEE
Yes
MFDS
Yes
IP (front/except for front)
IP35/IP32
Vandal-proof
IK06
Hot Key
Yes (2keys)
Brightness stabilization
Yes
Black Stabilizer
Yes
Factory Calibration
Yes (Delta E<5, Gamma 1.8~2.6/DICOM curve)
HW Calibration
Yes (True Color pro)
DICOM Compliant
Yes
Color Temperature
6500K/7500K/9300KManual (5000K ~ 10000K)
Flicker safe
Yes
HDR 10
Yes
HDR Effect
Yes
OSD Language
17 Languages
PBP
Yes (2PBP/3PBP/4PBP)
PIP
Yes
Picture Mode
(SDR) Custom, Mono, Vivid, HDR Effect, DICOM, Calibration 1, Calibration 2, (HDR) Custom, Vivid, Standard
Rotation & Mirror Mode
Yes
Failover Input Switch
Yes
Smart Energy Saving
Yes
User Preset
Yes
Super Resolution+
Yes
Uniformity
Yes
Net Quantity
1 N
Country of Origin
Korea
Manufactured By
LG Electronics Nanjing New Technology Co. Ltd, NO.346, YAOXIN ROAD ECONOMIC & TECHNICAL DEVELOPMENT ZONE, NANJING, 210038, PEOPLE'S REPUBLIC OF CHINA
Imported By
LG Electronics India Pvt. Ltd,A-24/6,Mohan Cooperative Industrial Estate, Mathura Road, New Delhi – 110044
