- 140㎛ pixel size
- 16bit A/D conversion
- IP68, Magnesium & Carbon-fiber Body
- Raw Image in 1.5 sec.(Wired) / 2 sec.(Wireless)
- Max. Uniform Load : 400kg / Max. Point Load : 200kg
All Spec
POWER
AC Input
100-240V (50/60Hz)
SENSOR(PANEL) UNIT
A/D Conversion
16bit
AP mode
YES
Auto Exposure Detection
YES
Data Output
16bit
Detachable Wire(Easy to plug / unplug)
Magnetic
Falling (IEC60601-1 Test Condition)
1.5m
Image storage on DXD
200
Pixel Pitch
140㎛
Power unit interface
Connect to Control Box
Scintillator
CsI
Semi-dynamic Acquisition
5fps
Sensor protection plate
Carbon Fiber Plate
Shock monitoring
YES
TFT Type
a-Si
Unit Interface
Connect to Control Box
Wired Communication
YES
CONTROL BOX
AC Power Cord
1.5m (White)
BATTERY
Hot swap
YES (1min)
STANDARD
RoHS
YES
BATTERY CHARGER
Bundle battery Q'ty
2
Slot Q'ty
2
