Pitch
2.5mm
LED Type
SMD
Life time (Typical)
100,000 Hours
Modules (w*h, ea)
6 (2*3)
Resolution (w*h, px)
256*180
Material
Aluminum
Dimension (w*h*d, mm)
Main : 640*450*59(163 w/back cover)
Secondary : 640*450*59(101 w/handle)
Weight (kg)
Main Cabinet : 13.8
Secondary : 7.5
Power Consumption - typical (watts, 48nit)
130 (Main) / 40 (Secondary)
Power Consumption - (watts, 300nit)
200 (Main) / 80 (Secondary)
Service access
Rear only
Pixels (w*h, Native)
4096*2160
Resolution (w*h, active area)
4096*2160
Pixel Density (px/SQM)
160,000
Cabinets (w*h, ea)
192 (16*12)
Dimension (w*h, mm)
10,240*5,400 (55sqm)
Weight (kg)
1,847
Power Supply
AC100-240 V ~, 50/60 Hz
Power Type
Built-in Power
Power Consumption - typical (watts, 48nit)
7,770
Power Consumption - (watts, 300nit)
15,480
Operation Temperature
0℃ to 40℃
Operation Humidity
10% to 80%
Storage Temperature
-20℃ to 60℃ (-4℉ to 140℉)
Storage Humidity
5% to 85%
Frame(Video) Rate (hz)
24, 25, 30, 48, 50, 60, 144@3D
Refresh Rate (@24hz)
3072@24Hz, 3840@60Hz
Brightness (nit, w/calibration)
48(DCI)/ 100 / 130 / 260 / 300
Contrast Ratio
≥4000:1
Color Space (Gamut)
DCI P3
Viewing Angle (H , V)
160, 160
Bit rate (Grey scale depth)
15bit@24/48/50Hz
Bit rate (Color Processing / color)
24 (72 / total)
Chromaticity Uniformity
White Uniformity:
within ±0.015 x, ±0.015 y
Color Temperature (white)
(x, y) = (0.314, 0.351) / DCI-P3 theater
Certification
DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
Cinema server compatibility
Dolby IMS3-L
Interface
RJ45, 2*HDMI, RS232C
