Pixel Configuration
Micro
Pixel Pitch (mm)
0.78
Module Resolution (W x H)
192 x 216
Module Dimensions (W x H, mm)
150 x 168.8
Weight per Module (kg)
0.16
No. of Modules per Cabinet (W × H)
4 x 2
Cabinet Resolution (W × H)
768 x 432
Cabinet Dimensions (W × H × D, mm)
600 × 337.5 × 44.9
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/Cabinet)
7.6
Weight per Square Meter (kg/m²)
37.5
Physical Pixel Density (pixels/m²)
1,638,400
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Die-casting Aluminum
Service access
Front and Rear
* Module can be accessed only from the front.
Max Brightness (After Calibration, nit)
500 / Peak 1,000
Color Temperature
7,300 K / 3,200~9,300 K (Adjustable by LED Assistant on PC)
Visual Viewing Angle (H×V)
150° × 150°
Brightness Uniformity
≥95%
Color Uniformity
±0.02Cx, Cy
Contrast Ratio
150,000 : 1 @ 10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Driver-IC Type
Common Cathode
Power Consumption (W/cabinet, Max.)
110
Power Consumption (W/cabinet, Avg.)
65
Power Consumption (W/m², Max.)
543
Heat Dissipation (BTU/h/Cabinet, Max.)
375
Heat Dissipation (BTU/h/Cabinet, Avg.)
222
Heat Dissipation (BTU/h/m², Max.)
1,853
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Controller
CSAB-0072
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature
0°C to +40°C
Operating Humidity
10-80% RH
IP Rating (Front / Rear)
IP50 / IP20
Certification
Safety 60950-1, EMC Class B, BS476 Part7 Class2Y (TBD)
Environment
RoHS
Optional Accessory
Wall Mount Kit, Frame Kit
