Model name
LSCC025
Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
2.50
Module Resolution (WxH)
120 x 135
Module Dimensions(WxH,mm)
300 x 337.5
Weight per Module (kg)
0.56
No. of Modules per Cabinet (WxH)
2 x 1
Cabinet Resolution (WxH)
240 x 135
Cabinet Dimensions (W x H x D, mm)
600 x 337.5 x 33.6
Cabinet Surface Area (㎡)
0.2
Weight per Cabinet (kg/unit)
5.0
Weight per Square Meter (kg/㎡)
24.69
Physical Pixel Density (pixels/㎡)
160,000
Flatness of Cabinet (mm)
± 0.1
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
Max. 800
Color Temperature (K)
3500 ~ 9000K (default: 6500K)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
97%
Color Uniformity
± 0.003CxCy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
84
Power Consumption (W/Cabinet, Avg.)
28
Power Consumption (W/㎡, Max.)
415
Heat Dissipation (BTU/h/Cabinet, Max.)
287
Heat Dissipation (BTU/h/Cabinet, Avg.)
96
Heat Dissipation (BTU/h/㎡, Max.)
1,415
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-10℃ to +45℃
Operating Humidity
0 ~ 80% RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE, FCC, ETL, EMC Class-A
Environment
RoHS, REACH
Controller
CVCA
90 degree corner cut
Yes
