Bottom Freezer Refrigerator with Swing Freezer Door (22.4 cu.ft.)

Specs

Reviews

Support

Bottom Freezer Refrigerator with Swing Freezer Door (22.4 cu.ft.)

LBN22517ST

Bottom Freezer Refrigerator with Swing Freezer Door (22.4 cu.ft.)

Print

All Spec

GENERAL

Capacity

22.4 cu.ft.

FEATURE

Freezer Door Type

Swing

MultiAir Flow System

Yes

Digital Temperature Controls

Internal Thumbwheels

Door Alarm

Yes

LoDecibel Operation

Yes

REFRIGERATOR

No. of Shelves

1 Full / 2 Split

Shelf Style

3 Fixed

Cantilevered Shelves

Yes

Shelf Construction

Tempered Glass

Bins

2 Humidity Crisper

Refrigerator Light

Reveal (2x40W)

REFRIGERATOR DOOR

No. of Door Bin

3

Door Bin Material

1 Piece Opaque

FREEZER

Upper Drawer

Wire

Lower Drawer

Wire

Ice Maker

Not Ready

Freezer Door Bin

Yes

Freezer Light

40W

MATERIAL AND FINISHES

Foam Door Insulation

Cyclo Pentane (No CFC, No HCFC)

Door Style

Contour

Bio Shield AntI Bacterial Door Shield

Yes

Toe Grille

Yes

Back

Flush & Metal cover over mechanical parts

Handles

Matching Commercial Handles

Color

Stainless Steel

Cabinet Color

Grey

Reversible Door

Yes

DIMENSIONS AND WEIGHT

Depth w/ Handles

34 1/2"

Depth w/o Handles

32"

Depth w/o Door

28 1/4"

Depth (Total with Door Open)

62"

Height to Top of Case

67 11/16"

Height to Top of Door Hinge

68 3/8"

Width

32 3/4"

Width (door open 90 deg. w/o handle)

34 1/8"

Installation Clearance

Sides 1/8" x Top 1" x Back 2"

Carton Dimensions (WxHxD)

35 1/8" x 72 1/2" x 36"

Weight (lbs): Unit/Carton

237/263

UPC CODE

UPC Code

772454050251

WARRANTY

Warranty

1 Year parts and Labour, 7 Years on the Sealed System
