Discontinued
75XS2C
Window Facing
75"
  • Brightness : 2,500 cd/m² (Typ.)
  • Life Time : 50,000 hours
  • Bezel : 12.8 mm(Even bezel)
  • Depth : 116mm
  • Interface : HDMI (2) / DP / DVI / RJ45 / IR / RS232C / USB / SD Card / External speaker out (L/R)

component-OBScountrySelectDesc

Window Facing

Panel

  • Screen Size
    75" (74.52" Measured Diagonal)
    Resolution
    3,840 x 2,160 (UHD)
  • Brightness (Typ., cd/m²)
    2500

Connectivity

  • Input
    HDMI(2), DP, DVI-D, Audio, USB, SD Card
    Output
    DP, External Speaker Out (L/R)
  • External Control
    RS232C (In/Out), RJ45, IR Receiver

Physical Specification

  • Bezel Width
    12.8 mm(Even bezel)
    Monitor Dimension (W x H x D)
    1,675.2 x 953.6 x 116 mm
  • Weight (Head)
    43 kg

Environment Conditions

  • Operation Temperature
    0°C to 40°C (w/o Direct Sunlight) / 0°C to 30°C (Direct Sunlight)
    Operation Humidity
    10% to 85%

Power

  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power

Power Consumption

  • Typ./Max
    585 W / 600 W
    Smart Energy Saving
    280 W

Standard(Certification)

  • Safety
    UL / cUL / CB / TUV
    EMC
    FCC Class "A" / CE / KC / VCCI
  • ErP / Energy Star
    Yes (EU Only) / No

Software Compatibility

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control
    (Software compatibility may change over time.)

Accessory

  • Basic
    Remote Controller (2 batteries included), Power Cord, HDMI Cable, Manual (ESG&EIG), IR Receiver(w/Ambient Light Sensor)
    Optional
    LSW630 (Wall Mount), AN-WF500 ** Stand is not available
  • Dimension
    • 75XS2C.dwg
    • 75XS2C.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
