WP400
webOS Box
  • LG webOS 4.0 Smart Signage Platform
  • Ultra HD Video Playback
  • Intuitive UX Dedicated for Digital Signage
  • Embedded CMS
  • Compatibility with LG SuperSign Solution and Signage 365 Care
webOS Box
MSRP $

Connectivity

  • Input
    HDMI (2), DP, USB 2.0 (2)
    Output
    HDMI, DP(Daisy chain only)
  • External Control
    RS232C in/out, RJ45 in, IR in

Mechanical Specification

  • Player Dimension (W x H x D)
    258 × 36.5 × 186 mm
    Weight
    1.4 kg
  • Carton Dimensions (W × H × D)
    314 x 124 x 359 mm
    Packed Weight
    2.26 kg

Key Feature(Hardware)

  • Key Feature (Hardware)
    Internal Memory 8GB (System 4GB, Available 4GB), Wi-Fi Built-in (ac combo), Thermal Sensor, Power Indicator, Local Key Operation

Key Feature (Software)

  • webOS ver.
    webOS 4.0
    Embedded CMS
    USB Auto Playback, Local Contents Scheduling, Group Manager
  • Fail over
    O
    Image Customization
    No Signal
  • Content Sync.
    RS-232C, Local Network
    Multi-screen
    PIP/PBP(4)
  • Screen Share
    O
    Video Tag
    O (2)
  • Play via URL
    O
    OSD Rotation
    O
  • Lock mode
    O (Home Dashboard, USB, OSD, IR Operation, Local Key, WiFi, Screen Share)
    Content Rotation
    O
  • Gapless Playback
    O
    Tile Mode Setting
    O (Max. 15x15)
  • Setting Data Cloning
    O (Network, USB)
    Firmware Update by Network
    O
  • SNMP(ver.2)
    O
    ISM Mode
    (Image Sticking Minimization)
    O
  • Status Mailing
    O
    Power Mgmt.
    DPM, On/Off Schedule, Holiday Schedule, Power on Status, Smart Energy Saving, Wake on LAN, Power on Delay
  • Control Manager
    O
    Daylight Saving Time
    O
  • Beacon
    O
    HDMI-CEC
    O *Compatibility may differ by equipment.
  • SI Server Setting
    O
    webRTC
    O

Environment Conditions

  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10% to 80%

Power

  • Power Supply
    100-240V~, 50/60Hz
    Power Type
    Built-In Power

Power Consumption

  • Typ./Max
    16 W / 22 W

Certification

  • Safety
    CB
    EMC
    CE Class A

Software Compatibility

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software
    SuperSign Control/Control+

Accessory

  • Basic
    Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
