Discontinued
49SM5KD
SM5KD Series
  • Brightness(Typ.): 450 cd/m²
  • Bezel : T/L/R 11.9 mm, B 18.0 mm
  • Depth : 54 mm
  • Interface : HDMI(2), DVI, DP, RGB, RJ45, IR, RS232C, USB
  • Built-in Speaker : 10W + 10W
SM5KD Series

Panel

  • Screen Size
    49"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness(Typ.,cd/m²)
    450

Connectivity

  • Input
    HDMI (2), DP, DVI-D, RGB, Audio, USB 3.0
    Output
    DP, Audio
  • External Control
    RS232C in/out, RJ in, IR Receiver, Pixel Sensor

Physical Specification

  • Bezel Width
    11.9 mm (T/R/L), 18 mm (B)
    Monitor Dimension (W x H x D)
    1,102.2 x 638.5 x 54 mm
  • Weight (Head)
    14.3 kg
    VESA™ Standard Mount Interface
    300 x 300

Environment Conditions

  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %

Power

  • Power Supply
    100-240 V~, 50/60 Hz
    Power Type
    Built-In Power

Power Consumption

  • Typ.
    85 W
    Smart Energy Saving
    60 W

Standard(Certification)

  • Safety
    UL / cUL / CB / TUV / KC
    EMC
    FCC Class "A" / CE / KCC
  • ErP / Energy Star
    Yes (EU Only) / Yes (Energy Star 7.0)

Media Player Compatibility

  • OPS type compatible
    Yes
    External Media player Attatchable
    Yes (MP500/MP700)

Software Compatibility

  • Content Management Software
    SuperSign Premium
    Control and Monitoring Software
    SuperSign Link

Accessory

  • Basic
    Remote Controller (included 2ea batteries), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
    Optional
    Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100), Touch Overlay (KT-T490)

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
