50UN343H (NA) | LG Global Business

Essential Commercial TV

50UN343H (NA)

Key Features

4K UHD
USB Cloning
Multi IR

Essential Commercial TV with 4K Active HDR

A TV on a hotel’s wall shows a bright and vivid screen.

* 55 inch
* All images in this page are for illustrative purposes only.

4K UHD, Vibrant Viewing in Ultra High Resolution

LG UHD TVs surpass your expectations every time. Experience lifelike picture quality and vivid colours with four times more pixel accuracy than Full HD.

The scenery displayed on the TV screen is vividly expressed, appearing as if it were real.

Multi IR

Multi-code IR function eliminates any remote control signal interference between TVs in rooms with multiple TVs Installed.

Setting data of the display can be stored on USB and transmitted to other displays.

USB Cloning

USB data cloning makes managing multiple displays more efficient for optimal operation. Instead of setting up each display one by one, data can be copied to a USB for one display and can be sent to the other displays through a USB plug-in.

All Spec

DISPLAY

Inch
50"
Resolution
3840 X 2160 (UHD)
Backlight Unit Type
Direct
Brightness
400
Dynamic Contrast Ratio (Dynamic MCI (Hz))
1,000,000:1
Static (Panel) Contrast Ratio
5000
Response Time(G to G, ms)
19ms
Refresh Rate
60Hz
Life span (hrs)
30,000

VIDEO

SoC
K8Lp
SoC (Marketing Name)
Quad
HDR_HDR 10 Pro
Yes
HDR_HLG
Yes
Game Optimizer
Yes

AUDIO

Speaker System
2.0 ch
AI Sound Pro / AI Sound
Yes

REQUIRED LISTING(CERTIFICATION)

Power Supply (Voltage, Hz)
AC 100 ~ 240V, 50/60Hz
Safety
UL
EMC
FCC

POWER

Power Consumption(Max)
135 W
Power Consumption(Typ)
112 W
Standby Power Consumption
0.5W Under

BROADCASTING SYSTEM

Digital (Terrestrial,Cable,Satellite)
ATSC, Clear QAM
Analog (NTSC / SECAM / PAL)
NTSC

DESIGN

Tool Name
UP8000
Stand Type
1 pole (Swivel : 50")
Front color
Ashed Blue

JACK INTERFACE

HDMI In
2 (2.0)
USB
1 (2.0)
RS-232C(D-Sub 9pin / Phone jack)
1 (Phone Jack Type)
External Speaker Out(3.5mm phone jack)<br>Audio Line Out(3.5mm phone jack)
1 (Spk-out 1, 1W)(Stereo, R: 1.0W, L: 1.0W, 8Ω)
LG SVC only (Phone jack type)
1
HDMI In (HDMI Ver.)
1 (2.0)
RF In
1 (Tuner)
AV In
1 (Phone Jack Type)
Digital Audio Out (Optical)
1 (Optical)

HOSPITALITY SOLUTION

Quick Menu (Version)
Yes (5.0)

MECHANIC

Kensington Lock
Yes
Credenza/Security Screw Hole
Yes
Lock Down Plate (for easy installing )
Yes
Weight without Stand (WxHxD)
12.1
Weight with Stand
15.3
Weight in Shipping
18.6
Size without Stand (WxHxD)
1121 x 651 x 57.1
Size with Stand (WxHxD)
1121 x 713 x 303
Size in Shipping (WxHxD)
1317 x 810 x 188
Bezel Width (L/R/U/B) : On Bezel
12.8/12.8/12.8/19.9
Bezel Width (L/R/U/B) : Off Bezel
7.3/7.3/7.8/18.4
Remote Control
Yes
Chromecast Dongle Anti-theft Cover
Yes (option)
Power Cable
Yes (1.8M,Straight Type)

SMART FUNCTION

webOS version
Yes (webOS22)
Smart Home (Launcher Bar)
Yes
Quick Access
Yes
HDMI-ARC
Yes (HDMI2)

OTHER FEATURE

USB Cloning
Yes
SNMP
Yes
Diagnostics
Yes (USB)
SI Compatible Protocol
Yes (ECI, RS232C)
HTNG-CEC
Yes(1.4)
Simplink(HDMI-CEC)
Yes(1.4)
IR Out
Yes (ECI, RS232C)
Multi IR Code
Yes
Hotel Mode / PDM / Installer Menu
Yes(PDM)
Lock mode
Yes (Limited)
Port Block
Yes
Welcome Video
Yes
Welcome Screen (Splash Image)
Yes
Insert Image
Yes
External Speaker Out
1 (Spk-out 1, 1W)(Stereo, R: 1.0W, L: 1.0W, 8Ω)
RJP (remote jack pack) Compatibility
YesTeleadapt/Guestlink (HDMI CEC)
USB Auto playback / USB Auto playback+ (playlist editing)
Yes / No
Moving Picture Playback (SD/HD/Plus HD)
Yes
Auto Off / Sleep Timer
Yes/Yes
Energy Saving mode
Yes

VERTICAL FUNCTION

Motion Eye Care
Yes

ETC

ECI (RJ12 jack)
1
VESA Compatible
Yes200x200
