LSBF Indoor LED Series

LSBF Indoor LED Series

LSBF Indoor LED Series

LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025
LG LSBF Indoor LED Series, LSBF025

Key Features

  • Pixel Pitch : 2.50 mm
  • Brightness : 600 nit
  • Easy Installation and Maintenance
  • Durable Frame Design
  • Compatibility with LG Software Solutions
  • IP Rating (Front / Rear) : IP50 / IP50
More
Print

All Spec

PHYSICAL PARAMETERS

  • Pixel Configuration

    Single SMD

  • Pixel Pitch (mm)

    2.5

  • Module Resolution (WxH)

    120x135

  • Module Dimensions(WxH,mm)

    300x337.5x13

  • Weight per Module (kg)

    0.95

  • No. of Modules per Cabinet (WxH)

    4x2

  • Cabinet Resolution (WxH)

    480x270

  • Cabinet Dimensions (W x H x D, mm)

    1,200x675x72

  • Cabinet Surface Area (㎡)

    0.81

  • Weight per Cabinet (kg/unit)

    23

  • Weight per Square Meter (kg/㎡)

    28

  • Physical Pixel Density (pixels/㎡)

    160,000

  • Flatness of Cabinet (mm)

    ±0.3

  • Cabinet material

    Die-casting Aluminum

  • Service access

    Front

OPTICAL SPECIFICATIONS

  • Max Brightness (After Calibration, nit)

    600

  • Color Temperature (K)

    3,200~9,300

  • Visual Viewing Angle (Horizontal)

    160

  • Visual Viewing Angle (Vertical)

    150

  • Brightness Uniformity

    0.97

  • Color Uniformity

    ±0.003Cx,Cy

  • Contrast Ratio

    5,000:1

  • Processing Depth (bit)

    14 (HDR10, HDR10 Pro)

  • Refresh Rate (@24Hz)

    3,840

  • Life Time (Brightness 50%)

    100,000

ELECTRICAL SPECIFICATIONS

  • Power Consumption (W/Cabinet, Max.)

    372

  • Power Consumption (W/Cabinet, Avg.)

    145

  • Power Consumption (W/㎡, Max.)

    460

  • Heat Dissipation (BTU/h/Cabinet, Max.)

    1,270

  • Heat Dissipation (BTU/h/Cabinet, Avg.)

    495

  • Heat Dissipation (BTU/h/㎡, Max.)

    1,570

  • Power Supply (V)

    100 to 240

  • Frame Rate (Hz)

    50 / 60

OPERATION SPECIFICATIONS

  • Operating Temperature(℃)

    -20℃ to +40℃

  • Operating Humidity

    10~80%RH

  • IP rating Front

    IP50

  • IP rating Rear

    IP50

STANDARD

  • Certification

    CE (EMC), FCC, cTUVus, CB, CE

ENVIRONMENT

  • Environment

    RoHS, REACH

CONTROLLER

  • Controller

    CVBA

Datasheet

extension : pdf
LSBF Series_Datasheet(low)_LG LED Signage_240130.pdf
