US670H Series

Key Features

Choose your Size

component-OBScountrySelectDesc

US670H Series
Design
  • Stand Type
    1 pole (Swivel 55/50/43")
    Front color
    Ceramic Black
Display
  • Inch
    50"
    Resolution
    3840 X 2160 (UHD)
  • Nano
    No
    Brightness
    400
Video
  • HDR_Dolby Vision
    No
    HDR_HDR 10 Pro
    Yes
  • HDR_HLG
    Yes
Audio
  • Speaker (sound output)
    10W + 10W
    Speaker System
    2.0 ch
  • DOLBY ATMOS
    No
    LG Sound Sync
    Yes (Required Bluetooth)
Broadcasting System
  • Digital (Terrestrial,Cable,Satellite)
    ATSC (Clear QAM)
    Analog (NTSC / SECAM / PAL)
    NTSC
  • Teletext (Closed caption) / Auto Teletext
    Yes/ No
Hospitality Solution
  • Pro:Centric Smart
    Yes (Smart)
    Pro:Centric Direct (version)
    Yes (4.0)
  • Pro:Centric Application (version)
    Yes (PCA3.8)
    Quick Menu (Version)
    Yes (4.0)
  • Pro:Idiom (H/W Type)
    No
    Pro:Idiom (S/W Type)
    Yes
  • Pro:Idiom (Mobile, Lite)
    Yes
Smart Function
  • webOS version
    Yes (webOS 5.0)
    Gallery Mode
    Yes
  • Web Browser
    Yes
    CP App
    Yes
  • Magic Remote Compatibility
    Yes (Ready, MR18HA)
    Mood Display
    No
  • Soft AP
    Yes
    WiFi (version)
    Yes (802.11ac)
  • Screen Share (Miracast)
    Yes
    Smart Share (DLNA)
    Yes
  • Bluetooth Audio Playback
    Yes
    LG Sound Sync/bluetooth
    Yes
  • Voice Recogion (Standalone/Solution)
    Yes
    IoT
    Yes
other Feature
  • USB Cloning
    Yes
    SI Compatible
    Yes (MPI, RS232C)
  • IR Out
    Yes (MPI,RS232C)
    Hotel Mode / PDM / Installer Menu
    Yes(Installer Menu)
  • One Channel Map
    Yes (LCM)
    IP Chanenel Manager
    No
  • External Speaker Out
    Yes(Int Variable /Fixed, 3.5mm, Stereo, Single ended Type(GND,L+,R+), 1W with 8Ω)
    Instant ON
    Yes
  • V-Lan Tag
    Yes
    External Clock Compatibility
    No
  • Full Touch Screen
    No
    b-LAN embedded
    Yes
  • Conformal Coating
    No
Vertical Function
  • Required Approval
    No
    Pillow Speaker
    No
  • Big Size Menu (Big Font UI)
    No
    Healthcare Headphone Mode
    No
  • Protection Cover (Glass)
    No
    Antimicrobial
    No
Jack Interface
  • Set Side
    HDMI In (2.0), USB 2 (2.0)
    Set Rear
    HDMI In (HDCP) 2 (2.0), RF In (Dual b-LAN), Digital Audio Out (Optical), RS-232C(D-Sub 9pin / Phone jack) (D-Sub 9pin), RJ45 (Usage Purpose) 2 (Ethernet, Aux), External Speaker Out(3.5mm phone jack) (Spk-out fixed 0.01W~1.00W and line out), TV link Configuration(phone jack type) (b_LAN Service), MPI Port (RJ12 jack), LG SVC only (Phone jack type) (CPU/PTC)
etc
  • VESA Compatible
    Yes
    200x200
    Kensington Lock
    Yes
  • Credenza/Security Screw Hole
    Yes
    Lock Down Plate (for easy installing )
    Yes
Mechanic
  • Weight without Stand
    11.5
    Weight with Stand
    14.5
  • Weight in Shipping
    18.3
    Size without Stand
    1130 * 663 * 86.3
  • Size with Stand
    1130 * 722 * 303
Power
  • Power Supply (Voltage, Hz)
    AC 120 V ~ 50 / 60 Hz
    Power Consumption(Max)
    140W
  • Power Consumption(Typ)
    66.0W
    Standby Power Consumption
    0.5W Under
  • Datasheet
    • US670H(NA)_Datasheet(low)_LG Commercial TV_200727.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
