Discontinued
SM5KD Series
  • Brightness(Typ.): 450 cd/m²
  • Bezel : T/L/R 11.9 mm, B 18.0 mm
  • Depth : 54 mm
  • Interface : HDMI(2), DVI, DP, RGB, RJ45, IR, RS232C, USB
  • Built-in Speaker : 10W + 10W

component-OBScountrySelectDesc

SM5KD Series
Panel
  • Screen Size
    43"
    Resolution
    1,920 x 1,080 (FHD)
  • Brightness(Typ.,cd/m²)
    450
Connectivity
  • Input
    HDMI (2), DP, DVI-D, RGB, Audio, USB 3.0
    Output
    DP, Audio
  • External Control
    RS232C in/out, RJ in, IR Receiver, Pixel Sensor
Physical Specification
  • Bezel Width
    11.9 mm (T/R/L), 18 mm (B)
    Monitor Dimension (W x H x D)
    969.6 x 563.9 x 54 mm
  • Weight (Head)
    10.0 kg
    VESA™ Standard Mount Interface
    200 x 200
Environment Conditions
  • Operation Temperature
    0°C to 40°C
    Operation Humidity
    10 % to 80 %
Power
  • Power Supply
    100-240 V~, 50/60 Hz
    Power Type
    Built-In Power
Power Consumption
  • Typ.
    75 W
    Smart Energy Saving
    55 W
Standard(Certification)
  • Safety
    UL / cUL / CB / TUV / KC
    EMC
    FCC Class "A" / CE / KCC
  • ErP / Energy Star
    Yes (EU Only) / Yes (Energy Star 7.0)
Media Player Compatibility
  • OPS type compatible
    Yes
    External Media player Attatchable
    Yes (MP500/MP700)
Software Compatibility
  • Content Management Software
    SuperSign Premium
    Control and Monitoring Software
    SuperSign Link
Accessory
  • Basic
    Remote Controller (included 2ea batteries), Power Cord, QSG, RGB Cable, Regulation Book, Phone to RS232C Gender, Memory cover
    Optional
    Stand (ST-432T), Media Player, Wall Bracket (LSW230B), VESA Adapter (AM-B220S), OPS Kit (KT-OPSA), HDBaseT (EB-B100), Touch Overlay (KT-T430)
  • Dimension
    • 43SM5KD.dwg
    • 43SM5KD.pdf
  • Software

    To download Software, Please visit the Software Download Page (Click).

  • Manual

    To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
