55XS2C component-copyModelName

XS2C Series

Discontinued

55XS2C component-copyModelName

XS2C Series

Key Features

Brightness : 2,500 cd/m2 (Typ.)
Life Time : 50,000 hours
Bezel : 9.9 mm (L/R), 12.0 mm (T/B)
Depth : 85.4 mm
Interface : HDMI (2) / DP / DVI / RJ45 / IR / RS232C / USB / External speaker out (L/R)

Inquiry to Buy

Add to Compare

component-OBScountrySelectDesc

Key Features

Brightness : 2,500 cd/m2 (Typ.)
Life Time : 50,000 hours
Bezel : 9.9 mm (L/R), 12.0 mm (T/B)
Depth : 85.4 mm
Interface : HDMI (2) / DP / DVI / RJ45 / IR / RS232C / USB / External speaker out (L/R)

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

XS2C Series

Outstanding Visibility

Increased Brightness

The brightness has been increased to 2,500 cd/m2 compared to the previous WX30 model, making the XS2C the ultimate screen for outdoor visibility.

Outstanding Visibility

Advanced Local Dimming

The backlighting in specific areas of the screen can be controlled to increase contrast and provide a clearer image.

Outstanding Visibility

QWP (Quarter Wave Plate)

FPR (Film-type Patterned Retarder) technology is embedded with a QWP which enables clear visibility even when the viewer is wearing polarized sunglasses.

Quiet Operation

Fan-Less Noise Reduction
The XS2C is the perfect choice for an in-window environment due to the removal of the cooling fan. Its operating noise level is under 25 dB, which is quieter than a recording studio (30 dB).

Enhanced Design Configuration

Slimmer Depth
The slimmer depth saves space for installation and makes the enclosure design slimmer.

Low Power Consumption Using The M+ Panel1

Cost Effective

Low Power Consumption Using The M+ Panel

The M+ panel offers excellent energy efficiency and cost savings and decreases power consumption by 30 compared to conventional RGB panels.

Cost Effective

Smart Brightness Control

The auto-brightness sensor and preset time scheduler save power whenever possible.

Product Reliability

Dust & Humidity Protection

The conformal coating enhances circuit board reliability by protecting it from dust, iron shavings, humidity and other harsh conditions.

Product Reliability

High Operating Temperature

The panel offers superb reliability under high operating temperatures and reduces cooling fan usage.

Easy Maintenance

Real-Time Remote Monitoring

When an alarm occurs, an email notification is sent through the SNMP using the SuperSign C or SI software. In case a malfunction or error occurs, real-time remote care is available.

Easy Maintenance

Saving System Log Files

The XS2C supports log file back-up for fault clarification when the display fails. This allows you to conveniently check when an error has occurred.

Panel

Screen Size

55"

Resolution

1,920 x 1,080 (FHD)
Brightness (Typ., cd/m²)

2500

Connectivity

Input

HDMI(2), DP, DVI-D, Audio, USB, IR Receiver, Pixel Sensor

Output

DP, External Speaker Out (L/R)
External Control

RS232C (In/Out), RJ45

Physical Specification

Bezel Width

9.9 mm (L/R), 12.0 mm (T/B)

Monitor Dimension (W x H x D)

1,238.4 x 712.4 x 85.4 mm
Weight (Head)

26.7 kg

Environment Conditions

Operation Temperature

0°C to 45°C (w/o Direct Sunlight) / 0°C to 35°C (Direct Sunlight)

Operation Humidity

10 % to 80 %

Power

Power Supply

100-240V~, 50/60Hz

Power Type

Built-In Power

Power Consumption

Typ./Max

240 W / 250 W

Smart Energy Saving

140 W

Standard(Certification)

Safety

UL / cUL / CB / TUV

EMC

FCC Class "A" / CE / KC / VCCI

Software Compatibility

Content Management Software

SuperSign W

Control and Monitoring Software

SuperSign C

Accessory

Basic

Remote Controller (2 batteries included), Power Cord, HDMI Cable, Manual (ESG&EIG)

Optional

WM-L640V(Landscape Wall-mount), WM-P640V(Portrait Wall-mount), KT-SP0, AN-WF500 ** Stand is not available

Dimension
- 55XS2C.dwg
- 55XS2C.pdf
Datasheet
- XS Series Leaflet(preview)_11710.pdf
Software

To download Software, Please visit the Software Download Page (Click).
Manual

To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
