4K UHD Signage

75UH7Q-E

Key Features

Resolution : 3,840 × 2,160 (UHD)
Brightness : 700 nits (Typ.)
Bezel Width : 12.9 mm (Even)
webOS Smart Platform
LG Shield

A large UH7Q is installed in a stadium cafeteria, brightly and clearly broadcasting a live soccer match on the screen.

* All images in this page are for illustrative purposes only.

Superb Picture Quality with Ultra HD Resolution

With the resolution of UHD, it makes the colors and details of the content vivid and realistic. In addition, the wide viewing angle provides clear content.

Convenient webOS Platform

The UH7Q is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.

_{* SoC : System On Chip

** SI : System Integrator}

High Brightness

The digital signage display UH7Q, with a great brightness of 700 nits, clearly delivers content even in bright stores.

Durability that Provides Reliability

Optimized for business environments, the UH7Q is protected against salt, dust, iron powder and humidity thanks to conformal partial coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring*, provide both reliability and satisfaction.

The UH7Q has conformal coating to protect the display even in salty or humid environments.

* When a physical impact occurs on the product, an alert is provided to the administrator through the media controller.

Comprehensive Security

webOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also, the webOS platform supports ETSI EN 303 645.

The UH7Q with LG Shield offers security features that protect its system and network.

SuperSign Solutions

SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.

Café managers are creating menus that will be displayed on the display installed on the café wall using content management software.

* SuperSign must be purchased separately.

All Spec

PANEL

Screen Size (Inch)
75
Panel Technology
ADS
Back Light Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60Hz
Brightness
700nit(Typ.)
Contrast Ratio
1,200:1
Dynamic CR
1,000,000:1
Color Gamut
BT709 95%
Viewing Angle (H x V)
178º x 178º
Color Depth (Number of Colors)
1.07 Billion colors
Response Time
8ms (G to G)
Surface Treatment (Haze)
25%
Life time
50,000Hrs (Typ.)
Operation Hours (Hours/Day)
24/7
Portait / Landscape
YES / YES

CONNECTIVITY

HDMI In
YES (3ea)
HDMI In (HDCP Ver.)
2.2/1.4
DP In
YES (HDCP 2.2/1.3)
RS232C In
YES
RJ45(LAN) In
YES (1ea)
IR In
YES
USB In
USB2.0 Type A (2ea)
Audio Out
YES
RS232C Out
YES

MECHANICAL SPECIFICATION

Bezel Color
Black
Bezel Width
12.9mm(Even)
Weight (Head)
35.7Kg(TBD)
Packed Weight
44.0Kg(TBD)
Monitor Dimensions (W x H x D)
1679.5 x 958.7 x 29.7mm(without IR, Handle)
Carton Dimensions (W x H x D)
1820 x 1115 x 200(TBD)
Handle
YES
VESA Standard Mount Interface
600 x 400 mm

FEATURE - HARDWARE

Internal Memory (eMMC)
16GB
Wi-Fi/BT (Built-in)
YES
Temperature Sensor
YES
Auto Brightness Sensor
YES (EU in-box / Others Acc.)
Acceleration(Gyro) Sensor
YES
Local Key Operation
YES

FEATURE - SOFTWARE

OS Ver. (webOS)
webOS 8.0
Local Contents Scheduling
YES
Group Manager
YES
USB Plug & Play
YES
Fail over
YES
Booting Logo Image
YES
No Signal Image
YES
RS232C Sync
YES
Local Network Sync
YES
PIP
YES
PBP
YES (4PBP)
Screen Share
YES
Video Tag
YES (4 Video Tag)
Play via URL
YES
Screen Rotation
YES
External Input Rotation
YES
Gapless Playback
YES
Tile Mode Setting
YES
Setting Data Cloning
YES
SNMP
YES
ISM Method
YES
Auto Set ID
YES
Status Mailing
YES
Control Manager
YES
Cisco Certification
YES
Crestron Connected
YES
Smart Energy Saving
YES
PM mode
YES
Wake on LAN
YES
Network Ready
YES
Beacon
YES
HDMI-CEC
YES
SI Server Setting
YES
webRTC
YES
Pro:Idiom
YES

ENVIRONMENT CONDITIONS

Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %

POWER

Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power

POWER CONSUMPTION

Typ.
160W (TBD)
Max.
247W (TBD)
BTU (British Thermal Unit)
546 BTU/Hr(Typ.), 843 BTU/Hr(Max) (TBD)
Smart Energy Saving (70%)
112W (TBD)
DPM
0.5W
Power off
0.5W

SOUND

Speaker (Built-in)
YES (10W x 2)

CERTIFICATION

Safety
CB / NRTL
EMC
FCC Class "B" / CE / KC
ERP / Energy Star
NA / O
ePEAT(US only)
YES

SOFTWARE COMPATIBILITY

SuperSign CMS
YES
SuperSign Control+
YES
SuperSign WB
YES
SuperSign Cloud
YES
Mobile CMS
YES
Connected Care
YES

LANGUAGE

OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic

ACCESSORY

Basic
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(6EA)
Optional
Wall Mount (LSW640A/B)

SPECIAL FEATURE

Conformal Coating (Power Board)
YES
IP Rating
IP5X

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
