THERMA V R32 Split

LG THERMA V R32 Split offers a powerful heating solution for indoor spaces. It can operate at extremely cold weather like -25℃ and heat water up to 65℃.
Features
  • 04-1_Revolutionary-R1-Compressor_Desktop_1564386776755

    Revolutionary R1 Compressor

    THERMA V R32 Split is equipped with the Revolutionary R1 Compressor. This advanced compressor especially improved the tilting motion of scroll, increasing overall efficiency and reliability. Furthermore, compressor operation ranges are improved to perform from 10Hz to 135Hz.

  • 04-2_Environmentally-Sustainable-Refrigerant_Desktop_1564386790066

    Environmentally Sustainable Refrigerant

    THERMA V R32 Split is equipped with R32 refrigerant, the environmentally sustainable refrigerant which has a Global Warming Potential of 675, 70% lower than that of R410A’s. With R32 refrigerant, THERMA V R32 Split is highly energy efficient as a greener heating solution.

*The result above was based on space heating at 35℃
*Space heating at 55°C received an A++ rating.
* Required Accessory : PWFMDD200(LG Wi-Fi Modem) and PWYREWO00
  • 07-1_Easy---Flexible-Installation_Desktop_1564387416441

    Easy & Flexible Installation

    THEMRA V R32 Split can be easily and flexibly installed in all types of houses. Integrated water components* in the indoor unit make installation much easier in shorter time. Moreover, extended refrigerant pipe length goes up to 50m, and the pipes can be connected in three different directions(forward, sideways, and backward), which makes installation neater and more flexible.

  • 07-2_Pre-installation-Setting_Desktop_1564387426839

    Pre-installation Setting

    Based on installation site information, installers can prepare presetting with LG Heating Configurator and save data into memory card from their office. At the site, then, installers can simply insert memory card at the back of remote controller to activate configuration data. This allows easy and quick commissioning for installers.

* Water components include flow sensor, water pump, expansion tank, air vent valve, safety valve, plate heat exchanger, strainer, controller, and electric heater.
